CHASSIS
MOUNTING
CONTROLLOGIX
7 SLOTS
20 INCH X 24 INCH X 8 INCH
Technical specifications for 1756-A7
Manufacturer
Rockwell Automation
Mounting
Panel Mount
Module Type
Chassis
Series
ControlLogix
Part Number/Catalog No.
1756-A7
Brand
Allen-Bradley
No. of slots
Seven (7) slots
Backplane Current, Chassis/Slot @ 1.2VDC
1.5 A
Backplane Current, Chassis/Slot @ 3.3VDC
4A/4 A
Backplane Current, Chassis/Slot @ 5.1VDC
15 A/6 A
Backplane Current, Chassis/Slot @ 24VDC
2.8 A/2.8 A
Orientation
Horizontal
No. of mounting tabs
Four (4)
Operating Temperature, Series B
0°C to +60°C (+32°F to +140°F)
Operating Temperature, Series C
-25…+60 °C (-13…+140 °F)
Storage Temperature
-40°C to +85°C (-40°F to +185°F)
Cabinet size (HxWxD), min
50.8 x 60.9 x 20.3 cm (20 x 24 x 8 in.)
Power dissipation, max
4.5 W
Slots
7
Power Dissipation (Max)
4.5 Watts
Dimensions
20 x 24 x 8 inches
Weight
2.4 pounds (1.1 kilograms)
Enclosure
Open
Backplane Current (5 Volts DC)
10 Amps
Backplane Current (24 Volts DC)
2.8 Amps
UPC
10612598129314
UNSPSC
32151704
