Allen-Bradley 1769-IQ32

Allen-Bradley 1769-IQ32

SKU: 1769-IQ32-FS
We have 6 in stock
$175.00
$175.00
the lowest price in the last 30 days
See product description

Estimated delivery:

- +
More payment options
Eligible for Next Day Delivery Order before 4 PM ET for same-day processing. More about shipping
All Parts Come with Our 24 Month Warranty Industry-leading protection for your purchase. More about warranty
Surplus, Refurbished, and Repairs Available Multiple options to meet your needs and budget

Secure payment options

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚… here.


  • 1769IQ32
  • I/O MODULE
  • COMPACTLOGIX
  • 32 POINT DC SINK/SOURCE INPUT
  • 24 VOLT DC
  • PLUG-IN CONNECTION
  • 0 TO +60 DEGREE C

Details of the Allen Bradley 1769-IQ32 I/O Module

As part of the Compact I/O module family, the Allen Bradley 1769-IQ32 I/O module is compatible with MicroLogix 1500 and CompactLogix controllers. This module's 32 24V dc high-density input channels allow sinking and sourcing wiring combinations. The unit is CE compliant for all relevant directives and has C-UL certification.

Allen-Bradley 1769-IQ32 I/O module

1769-IQ32 Key Features and Benefits

The 1769-IQ32 features reinforced insulation and an IEC Class 2 type 75V dc operating voltage. Other features include:

  • Open-style enclosure
  • Type 1+ IEC input compatibility
  • Replacement door
  • Terminal block

Technical Specifications of Allen-Bradley 1769-IQ32

The operating voltage range of this module is between 10 and 30 V dc at 30 °C (86 °F) and between 10 and 26.4 V dc at 60 °C (140 °F). The highest bus current draw at 5V dc is 170 mA, dissipating 4.6 total watts of heat.

Other technical specifications include:

  • Operating temperature: 0 °C to 60 °C (32 °F and 140 °F)
  • Storage temperature: -40 °C to 85 °C (-40 °F and 185 °F)
  • Maximum operating vibration rating: Between 10 and 500 Hz at 5G, 0.030-inch peak-to-peak, or 2G for relay operation
  • Operating voltage: IEC Class 2 type 75V dc
  • Weight: around 0.97 pounds
  • Dimensions: 4.65 by 3.43 by 2.07 inches

Applications

I/O modules like the 1769-IQ32 are frequently used for:

  • Device communication
  • Device control
  • Operation timing

They are beneficial when legacy machinery, systems, and devices cannot natively communicate with a desired industrial protocol.

Allen-Bradley 1769-IQ32

Installation and Configuration

This module's power supply distance rating is eight, meaning the distance between the module and the controller or power source cannot be greater than eight modules. To fulfill the power supply requirements of the 1769-IQ32, an extra power supply unit must be added since some CompactLogix controllers allow the installation of more than eight Compact I/O modules. The installation process for this module is the same as for the current CompactLogix rack. It is necessary to adhere to the same power supply distance rating while installing a CompactLogix I/O expansion bank.

The RSLogix 500 programming software is needed to configure this module when used with a controller like MicroLogix 1500, and you can select between the RSLogix 5000 or the Studio 5000 when utilizing the CompactLogix controller.
