Siemens 6SE6420-2AD25-5CA1

Siemens 6Se6420-2Ad25-5Ca1

Siemens 6SE6420-2AD25-5CA1

Regular price
Sale price
$1,895.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

  • AC DRIVE
  • MICROMASTER 420
  • FILTERED
  • 5.5 KW / 7.5 HP
  • 3 PHASE INPUT
  • 380-480 VAC
  • 15.6 AMP
  • 50/60 HZ
  • 3 PHASE OUTPUT
  • 13.2 AMP
  • 0-650 HZ
  • IP20
  • Replaces the 6SE6420-2AD25-5CA0

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
New 6SE6420-2AD25-5CA1-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

TECHNICAL SPECIFICATIONS

Siemens 6SE6420-2AD25-5CA1

The Siemens 6SE6420-2AD25-5CA1, a part of the highly renowned MICROMASTER 420 series, is an innovative frequency converter developed with state-of-the-art technology. This innovative product presents a practical solution for a wide range of applications across various industries.

Technical Specifications:

The device dimensions are 245 mm x 185 mm x 195 mm (H x W x D), ensuring it can comfortably fit within a compact industrial setup. It operates optimally under an ambient temperature range of -10°C to +50°C, thereby offering extensive adaptability to diverse operational conditions. Its net weight stands at 1.02 kg, thus ensuring easy portability.

The 6SE6420-2AD25-5CA1 operates at an input voltage range of 380 V to 480 V AC, at a frequency of 47 – 63 Hz. It delivers an output power of 5.5 kW, which is adequate for a range of small to medium-sized applications. The model offers an extensive output frequency range of 0 - 650 Hz. This wide range ensures that the drive can be tailored to meet the specific needs of the application.

The Siemens 6SE6420-2AD25-5CA1 comes with integrated safety features such as short-circuit protection, overvoltage/under voltage protection, and overtemperature protection. This ensures that the device's operational integrity is safeguarded under all circumstances.

This model supports the RS485 interface allowing it to communicate and exchange data with various automation systems efficiently. It is equipped with Modbus RTU communication protocol which is commonly used in a wide range of industrial automation systems.

The 6SE6420-2AD25-5CA1 adheres to the International Protection (IP) code standard IP20, ensuring its durability and capability to function efficiently in non-hazardous environments. The model has integrated programmable digital and analog input/output channels for flexible system integration. Furthermore, it allows users to customize acceleration and deceleration times to achieve an optimal balance between speed and torque.

The drive is designed with energy-saving in mind. It has an automatic energy-saving mode which allows for optimal use of power, thus contributing to more sustainable and cost-effective operations. The model 6SE6420-2AD25-5CA1 is equipped with an intelligent MICROMASTER Profibus DP that enables streamlined, efficient communication with various automation components. This feature paves the way for swift configuration and commissioning.

Built-In EMC Filter:

The inverter drive is equipped with an integrated EMC filter, designed to minimize electromagnetic interference. This function facilitates the device's compatibility with other electronic equipment and adheres to EMC directive 2014/30/EU.

Advanced Motor Control:

The device utilizes advanced V/f control (Voltage/frequency) ensuring smooth and efficient motor operations. This advanced motor control technology enables high-precision speed control and high starting torque.

Added Features:

This device is known for its trip-free operation. In case of disturbances like voltage dips, the device can continue operating without triggering a system trip, ensuring uninterrupted operations. The 6SE6420-2AD25-5CA1 model offers comprehensive monitoring capabilities. It allows for the tracking of parameters such as voltage, current, frequency, and power, which can be helpful in system diagnostics and preventative maintenance.

The drive allows for flexible configuration of its I/Os, including three digital inputs, one analog input, one digital output, and one analog output. This ensures adaptability and compatibility with a wide array of external devices and control systems.

The model is also equipped with a flying restart capability, allowing the device to reconnect to a spinning motor after a brief power interruption, minimizing downtime.

Despite its host of powerful features, the Siemens 6SE6420-2AD25-5CA1 boasts a compact design. This is advantageous in environments where space is at a premium, as it can fit into tight spaces without compromising functionality or performance.
