Allen-Bradley 1756-IB16
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1756-IB16 is a robust 16-point DC input module designed for the ControlLogix system, operating optimally at a 24 Volts DC nominal input with a 12/24 Volt DC sink voltage category. It is compatible with the 1756 ControlLogix chassis and works efficiently with the 1756-TBNH and 1756-TBSH removable terminal blocks, allowing flexible termination of input signals. Ideal for both stand-alone and complex applications like Distributed Control Systems, the 1756-IB16 provides user-configurable change of state detection for swift input response, operating within a voltage range of 10 to 31.2 Volts DC and an isolation voltage of 250 Volts continuous.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-IB16 |
| Series | ControlLogix |
| Inputs | 16 |
| Module Type | Digital DC Input Module |
| No. of Inputs | Thirty-Two (32) Inputs |
| Input Voltage | 12-24 Volts DC Sink |
| Operating Voltage Range | 10-31.2 Volts DC |
| Module Keying | Electronic, software configurable |
| Maximum Operating Current | 10 milliamperes at 31.2 Volts DC |
| Input Delay Time | 2 milliseconds plus selected filter time |
| Maximum Input Current, Off-State | 1.5 milliamperes |
| Minimum Operating Current | 2 milliamperes at 10 Volts DC |
| Input Delay Time, OFF to ON | Hardware delay: 290 µs nom/1 ms max + filter time |
| Input Delay Time, ON to OFF | Hardware delay: 700 µs nom/2 ms max + filter time |
| Power Dissipation (Max) | 5.1 W @ 60 °C (140 °F) |
| RSLogix 5000 Software | Verson 8.02.00 or later |
| Backplane Current at 24 Volts | 2 milliamperes |
| Backplane Current at 5.1 Volts | 120 milliamperes |
| UPC | 10612598171290 |
| Thermal Dissipation | 21.1 BTU/hr @ 60 °C (140 °F) |
| Removeable Terminal Block(s) | 1756-TBCH 1756-TBS6H |
| Programming software | RSLogix 5000 Software Verson 8.02.00 or later; Studio 5000 |
