Allen-Bradley 1768-PA3

allen-bradley-1768-pa3

Allen-Bradley 1768-PA3

Regular price
Sale price
$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 1768-PA3 CompactLogix power supply is designed for the 1768 series, providing essential backplane power for attached modules without supplying output power. It operates efficiently with dual-input options of 85 - 265VAC or 108 - 132VDC, and achieves a typical efficiency rate of 75%. The module features a DIN rail or panel mount open-type enclosure, includes LED status indicators for real-time monitoring, and accommodates 14 to 22 AWG wire. With internal overcurrent protection, achieved via a non-replaceable soldered fuse, and supported by user-supplied overcurrent protection up to 15 Amps, the 1768-PA3 ensures robust performance with a maximum input power of 120 VA or 120 W.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1768-PA3-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1768-PA3
Product LineCompactLogix
Product Type:Power Supply Module
Module TypeAC Power Supply Module
Input Power85…265V ac; 108…132V dc
SoftwareRSLogix5000
Input Frequency Range47…63 Hz (85…265V ac)
Shipping Weight2 lbs.
Input Power, Max120 VA/120 W
Efficiency75% Typical
Shipping Dimensions8X8X5 in.
Isolation Voltage30 Volts Continuous
Inrush Current, Nom25 A @ 85…132V ac50 A @ 195…265V ac25 A @ 108…132V dc
Inrush Current, Max50 A @ 85…132V ac80 A @ 195…265V ac
Backplane Current1.4 Amps at 24 Volts
Power Dissipation, Max30 W
Power Consumption33.6 Watts
Internal Overcurrent ProtectionNon-replaceable fuse is soldered in place
Recommended External Overcurrent Protection4…6 A @ 28.5…36.7 A2 S
Power Dissipation7.5 Watts
EnclosureNone (open-style)
UPC10612598307569
