Allen-Bradley 1769-IF4

Allen-Bradley 1769-If4

Allen-Bradley 1769-IF4

Regular price
$450.00
Sale price
$450.00
We currently have 3 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚ here.


  • I/O MODULE
  • COMPACTLOGIX
  • 4 CHANNEL
  • VOLTAGE/CURRENT ANALOG INPUT
  • 24 VDC
  • 0-20 MA
  • SCREW CONNECTION

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1769-IF4-FS $450.00 USD 2 Year Extended Warranty 3 In Stock in US!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

TECHNICAL SPECIFICATIONS

The 1769-IF4 CompactLogix controller is an analog input module. When used with MicroLogix 1500 or 1769 CompactLogix controllers, this module is set up using the RSLogix 500 or the RSLogix 5000 / Studio 5000 programming environments.

The module features four single-ended or differential inputs. Their full-scale analog current and voltage ranges are 0 to 21 mA, 3.2 to 21 mA, and 10.5V dc, -0.5 to 10.5V dc, -0.5 to 5.25V dc, respectively. However, the usual operating ranges for the current are 0…20 mA, 4…20 mA, and ±10V dc, 0 to 10V dc, 0 to 5V dc, and 1 to 5V dc for the voltage. An Analog to Digital (ADC) circuit with a Delta-Sigma conversion type is built into this module. The conversion module has a 14-bit (unipolar) and 14-bit plus sign (bipolar) resolution. The module can configure the data it processes in engineering units, scaled for PID, percent range, or raw data.

The 1769 Compact I/O modules may be adjusted using the parameters provided, such as process warnings, input filtering, real-time sampling, etc. The inbuilt open-circuit detection is immediately enabled when a channel is enabled. This open circuit detection also turns on the module's under-range error bit. The controller can be alerted to errors when the module detects them. These errors can be shown as non-fatal system errors that may also be connected to a monitoring system such as HMI (Human Machine Interface) or SCADA (Supervisory Control and Data Acquisition).

A compact analog I/O module by Allen-Bradley is the 1769-IF4. Analog data may be digitally transformed and stored. The four differential or single-ended channels in this module may auto-calibrate when they are first engaged or when their configuration differs from that of the channel before it. It should be noted that this module does not provide loop power for analog inputs and that an external power source meeting the needs of the input transmitter is necessary.

Other characteristics of the 1769-IF4 include a common mode rejection ratio of more than 60 dB at 50 and 60 Hz and a normal mode rejection ratio of -50 dB at 50 to 60 Hz. It has an open-type enclosure and can be mounted on either a DIN rail or a panel. Solid 22-14 AWG and stranded 22-16 AWG connecting cables are compatible with the 1769-IF4. This module features an LED status indicator and measures 87 mm x 35 mm x 118 mm.

The maximum current consumption of the 1769-IF4 is 120 mA at 5V dc and 60 mA at 24V dc. The maximum common mode voltage per channel is 10V dc, and the rated operating voltage is 30V ac or 30V dc. The operating temperature range for the 1769-IF4 is 0 °C to +60 °C (32 °F to +140 °F), whereas the storage temperature range is -40 °C to +85 °C (-40 °F to +185 °F). The module operates with 10 to 500 Hz, 5 G, and 0.030 peak-to-peak vibrations. Its working height is 2000 meters, and its non-condensing relative humidity ranges from 5 to 95%.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1769-IF4
Product LineCompactLogix
Module Type4 Channel Analog Input Module
Input TypeAnalog Input
Product TypeAnalog Input Module
SoftwareRSLogix5000
Compatible Controllers:MicroLogix 1500; 1769 CompactLogix
Communication Cable 4 Point
No. of Inputs:4 Differential and Single Ended Inputs
Power Supply Distance rating:8
Shipping Weight2 lbs.
Shipping Dimensions8X8X5 in.
Input current range:0-21 mA
SeriesA and B
Current signal normal ranges:0-20mA; 4-20 mA
Converter TypeDelta Sigma
Current signal full range:0-21 mA; 3.2 - 21 mA.
Input voltage range:0-10.5VDC
Backplane Current1.4 Amps at 24 Volts
Voltage signal normal ranges:±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC
Power Consumption33.6 Watts
Voltage signal full range:±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC
External Power Switch24 VDC
Power Dissipation7.5 Watts
Resolution:14 bits (unipolar) 14 bits plus sign (bipolar)
UPC10662468992937
Rated working voltage:30VAC; 30VDC
Programming SoftwareRSLogix 500; RSLogix 5000; Studio 5000
