TECHNICAL SPECIFICATIONS

The 1769-L27ERM-QBFC1B is a CompactLogix 5370 L2 controller designed and engineered by Allen Bradley. Controllers from the type CompactLogix 5370 L2 have an internal power supply. As a result, you don't need to consider the power supply's distance rating while placing the controller. The Small I/O modules used in CompactLogix 5370 L2 systems as local extension modules make use of a Compact Bus. You must additionally consider these Compact I/O modules' distance rating from the power supply while installing them. Additionally, it has 2 EtherNet/IP ports with compatibility for both ring and linear topologies. Scalability was considered when designing the 5370 L2 controllers. This covers a wide range of applications and offers several cutting-edge functions.

test

Manufacturer	Industrial Automation / Allen-Bradley
Brand	Allen-Bradley
Part Number/Catalog No.	1769-OW8I
Product Family:	Compact I/O
Product Line	CompactLogix
Product Type:	Discrete Output Module
Module Type	Output Module
Module Type	Output Module
No. of outputs:	Eight (8) Individually Isolated
Input Type	Relay Output
Power Supply Distance rating:	8
I/O Type	Contact
Programming software:	RSLogix 500, RSLogix 5000; Studio 5000
Software	RSLogix5000
Compatible controllers:	MicroLogix 1500; CompactLogix controllers
Communication Cable	8 Point
Voltage Category:	AC/DC normally open relay
Shipping Weight	2 pounds

Operating Voltage range:	5 to 265V ac 5 to 125V dc
Shipping Dimensions	8 x 8 x 5 inches
Signal delay, On:	10 ms
Series	A and B
Wire Type	Copper 90 degrees
Bus Current draw, 5.1 V:	125 mA
Solid Wire Size	22 to 14 AWG
Bus Current draw, 24 V:	100 mA
Stranded Wire Size	22 to 16 AWG
Heat Dissipation:	2.83 Watts
UPC	10662468992913
Slot width:	1
UNSPSC	32151705
Mounting:	DIN Rail or Panel Mount
Dimensions:	118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.) Height with mounting tabs 138 mm (5.43 in.)
Power Supply:	1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Wire Size:	(22…14 AWG) solid (22…16 AWG) stranded
