Allen-Bradley 1769-PA2

Allen-Bradley 1769-Pa2
Allen-Bradley 1769-Pa2

Allen-Bradley 1769-PA2

Regular price
Sale price
$95.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 1769-PA2 is a versatile CompactLogix I/O power supply designed to seamlessly integrate into CompactLogix assemblies or expansion banks, supporting up to eight 1769 modules on either side. Operating within an input range of 85-265VAC and a frequency of 47-63 Hz, it offers a current capacity of 2.0A at 5VDC and 0.8A at 24VDC, making it suitable for a variety of applications. The compact dimensions of 118 x 70 x 87 mm and a weight of 525 g facilitate easy installation on a DIN rail or mounting plate, while its compliance with multiple safety and emission standards, including UL Class 1, Division 2, reinforces its reliability in industrial environments.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 1769-PA2-R 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

ManufacturerIndustrial Automation / Allen-Bradley
BrandAllen-Bradley
Part Number/Catalog No.1769-PA2
Module TypeAC Power Supply Module
Product Type:I/O Power Supply
Product LineCompactLogix
Input Power120 Volts AC
Input Voltage range:85…265V AC
SoftwareRSLogix5000
Input frequency range:47…63 Hz
Shipping Weight2 pounds
Power supply distance rating:8; 8 I/O modules can be connected on either side of the power supply for a maximum of 16 module.
Power consumption:100VA @ 120V AC; 130VA @ 240V AC
Shipping Dimensions8 x 8 x 5 inches
Shipping Dimensions8 x 8 x 5 inches
Power dissipation:8 W @ 60 °C (140 °F)
Enclosure Type RatingNone (Open Style)
Current capacity @ 5V DC:2.0 A
Wire TypeCopper-90 degrees
Current capacity @ 24V DC:0.8 A
Solid Wire Size22 to 14 AWG
Inrush current, max:25 A @ 132V AC
Stranded Wire Size22 to 16 AWG
Fuse type:Littelfuse 02153.15MXP; Wickmann 19195-3.15A
UPC10662468992951
Dimensions (HxWxD), approx.:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.) height including mounting tabs is 138 mm (5.43 in.)
Weight:525 g (1.16 lb)
Wire size:14 AWG (2.5 mm2 ) solid copper wire rated at 90 °C (194 °F) or greater, 1.2 mm (3/64 in.) insulation max
Certifications:c-UL-us; CE; C-Tick
