Allen-Bradley 1783-BMS20CL

Allen - Bradley 1783 - Bms20Cl

Allen-Bradley 1783-BMS20CL

$2,090.00
$2,090.00
We currently have 2 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1783-BMS20CL-FS $2,090.00 USD 2 Year Extended Warranty 2 In Stock in the United States!
Description

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.

  • 1783BMS20CL
  • STRATIX 5700
  • 16 COPPER 10/100 PORTS
  • 2 COMBO(COPPER OR SFP SLOT) 10/100PORTS
  • 2 SFP 10/100 SLOTS
  • LITE FW

Repair & Service
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 1783-BMS20CL

Alarm Relay1 A @ 30V DC or 0.5 A @ 48V DC
Wire size, ground connection4.0 mm2 (12 AWG) min, stranded copper wire
Wire size, alarm connection0.5…0.8 mm2 (20…18 AWG) solid or stranded, UL/CSA- rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire, 6.3 mm (0.25 in.) ±0.5 mm (0.02 in.) strip length
Wire size, DC power connection0.5…0.8 mm2 (20…18 AWG) solid or stranded copper wire rated at 75 °C (167 °F) or greater, 1.2 mm (3/64 in.) insulation max, 6.3 mm (0.25 in.) ±0.5 mm (0.02 in.) strip length
Wire size, Ethernet connectionRJ45 connector according to IEC 60603-7, 2- or 4-pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
Power Dissipation30 W
Power Supply12…48V DC
No. of Gigabit combo PortsTwo (2)
No. of Fast Ethernet Copper PortsSixteen (16)
No. of PortsTwenty (20);
ManufacturerRockwell Automation
BrandAllen-Bradley
SeriesStratix 5700
Part Number1783-BMS20CL
Product typeManaged Ethernet switch
Total ports20
Copper ports16
Fiber ports2
Combo ports2
Power input12 to 48 Volts DC
Operating temperature-40 to 60 degrees Celsius
UPC886739973538
