Allen-Bradley 2198-D012-ERS4

Allen-Bradley 2198-D012-Ers4

Allen-Bradley 2198-D012-ERS4

The Allen-Bradley 2198-D012-ERS4 Servo Drive is a sophisticated dual-axis inverter designed to meet the demanding needs of modern automation systems. It stands out as a powerful and reliable solution for industrial automation, offering high bandwidth, robust output currents, and versatile power input capabilities. Its design ensures precise control and consistent performance, making it an asset in any automated system.

Technical Specifications:

The drive is capable of handling DC input currents ranging from 458 to 747V DC, with a current draw of 5.3 ADC. This versatility in power input options enhances the drive's adaptability to different power supply configurations in industrial settings.

This Allen-Bradley 2198-D012-ERS4 boasts impressive bandwidth capabilities with a maximum velocity loop bandwidth of 400 Hz and a current loop bandwidth of 1000 Hz. These high bandwidths enable precise and responsive control, ensuring optimal performance even in highly dynamic environments.

In terms of output, the drive delivers a continuous output current of 5.0 A (rms) and a peak current of 7.0 A (0-pk). This allows the drive to maintain robust and consistent power delivery, supporting various motor types and sizes. The continuous power output operates within a three-phase voltage range of 324 to 528V rms, making it suitable for heavy-duty applications that require sustained power.

Operation and Configuration:

Operating the Allen-Bradley 2198-D012-ERS4 involves integrating it into an EtherNet/IP network, facilitating seamless communication and control across various industrial devices. The configuration process begins with connecting the drive to the appropriate power supply and ensuring that all wiring meets the specifications.

Once the hardware setup is complete, the next step is to configure the drive using Studio 5000 Logix Designer software. This software provides an intuitive interface for setting up the drive's parameters and integrating it with the broader control system. Operationally, the Allen-Bradley 2198-D012-ERS4 excels in delivering consistent and reliable performance.

Maintenance and Troubleshooting:

Regular maintenance routines should include visual inspections, cleaning, and system diagnostics to detect and address potential issues before they lead to significant downtime.

Visual inspections should be conducted periodically to check for signs of physical damage, loose connections, or overheating. Inspecting the drive's housing and connectors ensures that all components are securely in place and that there are no visible signs of wear or damage. Using compressed air to remove dust and ensuring adequate ventilation can help maintain optimal operating temperatures.

When troubleshooting issues with the Allen-Bradley 2198-D012-ERS4, start by referencing the error codes and diagnostic information available through the software. Common issues such as motor stalling, unexpected shutdowns, or erratic movements can often be traced back to incorrect configuration settings, electrical noise, or hardware faults.

A crucial first step is verifying that all parameter settings match the motor and application specifications. Ensuring that all connections are secure and that the drive is properly grounded can resolve many issues related to electrical noise or communication errors.

Frequently Asked Questions:

What is the AC input frequency for the Allen-Bradley 2198-D012-ERS4, and how does it contribute to the drive's performance?

The Allen-Bradley 2198-D012-ERS4 operates with an AC input frequency of 4 kHz, contributing to its efficient and effective performance. This high frequency ensures rapid response times and precise control, enhancing the drive's overall efficiency in demanding applications.

What is the nominal continuous power output of the Allen-Bradley 2198-D012-ERS4?

The continuous power output is rated at a nominal 3.4 kW, ensuring that the Allen-Bradley 2198-D012-ERS4 can handle substantial loads consistently and efficiently in various industrial applications.

What is the internal capacitance of the Allen-Bradley 2198-D012-ERS4?

The internal capacitance of the drive is 165 ?F, contributing to its ability to manage energy efficiently and maintain stable operation under varying load conditions.

Product Specifications Table

Attribute Specifications
Series Kinetix 5700
Horsepower 4.5 Hp
Voltage 324-528 Vrms
Dimensions 358 x 55 x 26.75 mm
Communication Interface Ethernet/IP
Software Compatibility Studio 5000 Logix Designer
Ambient Temperature Range 0 to 40°C
Control Method V/F control
Input/Output Frequency Range 4 kHz
Mounting Type Panel Mount

Allen-Bradley 2198-D012-ERS4

Regular price
$6,990.00
Sale price
$6,990.00
We currently have 2 in stock.
