Allen-Bradley 2198-H008-ERS

The Allen-Bradley 2198-H008-ERS is a robust and versatile member of the Kinetix 5500 Servo Drive series, engineered for high-performance motion control applications. Designed to support a wide input supply voltage range, this servo drive is an adaptable solution for various industrial environments.

Technical Details:

The Allen-Bradley 2198-H008-ERS is a highly adaptable servo drive within the Kinetix 5500 series, specifically engineered to meet the demanding requirements of modern industrial automation. This drive boasts flexible input voltage specifications, supporting both single-phase (195-264V rms with a nominal 240V) and three-phase (195-264V rms with a nominal 240V or 324-528V rms with a nominal 480V) configurations.

Delivering a continuous output current (rms) of 3.5 A. The Allen-Bradley 2198-H008-ERS offers an output power range from 0.5 kW to 1.6 kW, tailored to the input voltage and phase configuration. Its peak output current (0-peak) stands at 8.8 A, while the continuous output current (0-peak) remains at 3.5 A. Designed for versatility, the Allen-Bradley 2198-H008-ERS can function both as a standalone unit and within multi-axis configurations. It seamlessly integrates with other servo modules in various setups such as shared DC, shared AC, shared AC/DC hybrid, and shared DC/AC, enhancing the flexibility of system design.

Mounting Instructions:

Mounting the Allen-Bradley 2198-H008-ERS requires careful attention to detail to ensure optimal performance and safety. The location should be free from excessive dust, moisture, and corrosive environments. Ensure that the ambient temperature does not exceed the specified operating range of the drive. When positioning the Allen-Bradley 2198-H008-ERS, maintain sufficient clearance around it to facilitate airflow and cooling. The drives built-in cooling system relies on proper ventilation to dissipate heat effectively. Refer to the installation manual for specific clearance requirements, and avoid placing any obstructions near the drives ventilation openings.

For electrical connections, ensure that all power and signal cables are correctly rated for the application and meet the necessary safety standards. Carefully route the cables to avoid any sharp bends or physical damage, and secure them using cable ties or clamps to prevent strain on the connections. Double-check all wiring connections for accuracy and tightness before powering up the drive.

Regular Maintenance:

Conduct routine inspections of the servo drive to monitor its physical condition. Look for any indications of wear, damage, or loose connections. Ensure that the cooling system, if present, remains clear of debris and obstructions to maintain optimal performance. If the Allen-Bradley 2198-H008-ERS is equipped with a cooling mechanism, such as a fan or heatsink, verify its proper operation. Regularly clean or replace air filters to ensure efficient heat dissipation and prevent overheating.

Regularly back up the drives configuration settings and parameters. This practice is essential for quickly restoring the drive to its previous operational state in case of failure or when a replacement is necessary.

Frequently Asked Questions:

What is the significance of the current loop frequency in the Allen-Bradley 2198-H008-ERS?

The current loop frequency of 1000 Hz in the Allen-Bradley 2198-H008-ERS is a measure of how quickly the drive can respond to changes in the motor current. A higher frequency allows for more precise and rapid control of the current.

What are the physical dimensions and weight of the Allen-Bradley 2198-H008-ERS?

Physically, the Allen-Bradley 2198-H008-ERS is a Frame Size 1 servo drive, weighing 3.0 lbs (1.4 kg) and measuring 1.97 x 8.90 x 8.46 inches (50 x 226 x 215 mm).

What are the peak output current and efficiency ratings of the Allen-Bradley 2198-H008-ERS?

The Allen-Bradley 2198-H008-ERS features a peak output current (rms) of 6.25 A and operates with a commendable efficiency of 97%.
