Allen-Bradley 2198-H025-ERS

The Allen-Bradley 2198-H025-ERS stands as a formidable member of the Kinetix 5500 Servo Drive family. With a wide input voltage range, robust output current capabilities, and a scalable power delivery system, this servo drive stands as a robust and adaptable solution for integrated motion control over Ethernet/IP in industrial automation.

Electrical Features:

The Allen-Bradley 2198-H025-ERS boasts formidable electrical specifications, making it a versatile and efficient component for a range of industrial applications. Operating within a 3-phase system, the drive accommodates a nominal voltage of 240V with an input supply voltage range spanning from 195-264V rms. This flexibility ensures compatibility with a broad spectrum of power supply configurations, enhancing its adaptability in diverse industrial settings. For scenarios requiring higher voltage, the drive demonstrates its robustness by supporting 3-phase input voltages ranging from 324-528V rms, with a nominal voltage of 480VAC.

The continuous output current (rms) of 8.0 A underscores the drives capability to deliver sustained power for consistent performance. In instances demanding peak output, the drive excels with an impressive 11.3 A peak output current, showcasing its ability to handle dynamic and demanding operational conditions. This dynamic range in output current positions the servo drive as a versatile solution capable of meeting the demands of varying motion control applications. The output power specifications further highlight the drives capabilities, with a power range extending from 4.0 kW to 8.3 kW.

Physical Features:

The physical features of the Allen-Bradley 2198-H025-ERS combine a compact design with robust construction, making it an ideal solution for modern industrial environments. The drives sleek and space-efficient build reflects a commitment to optimizing real estate within control panels, ensuring seamless integration into diverse automation setups. Its form factor aligns with the evolving needs of industrial spaces, where efficiency and space utilization are paramount. connectivity enhances the drives usability within integrated motion control systems, emphasizing its role as a critical component in the broader automation framework. The design underscores user-friendly deployment, ensuring ease of integration with existing systems and minimizing setup complexities.

The sturdy construction of the Allen-Bradley 2198-H025-ERS serves as a testament to its durability in demanding industrial environments. Engineered to withstand the rigors of continuous operation, the drives robust build contributes to its reliability and longevity. This durability factor is essential for maintaining consistent performance in industrial settings where equipment resilience is crucial.

Regular Maintenance:

Regular maintenance of the Allen-Bradley 2198-H025-ERS involves periodic checks and assessments to ensure optimal performance. Monitoring input voltage conditions, output currents, and power levels are essential aspects of routine inspections. Attention to cooling systems, if applicable, is crucial to prevent overheating and ensure longevity. Additionally.

A proactive and systematic approach to maintenance enhances the operational lifespan of the Allen-Bradley 2198-H025-ERS, reinforcing its role as a dependable component in industrial automation systems.

Frequently Asked Questions:

What cooling mechanism is integrated to prevent overheating in Allen-Bradley 2198-H025-ERS?

The Allen-Bradley 2198-H025-ERS incorporates features that prioritize efficient heat dissipation. This is to prevent overheating and ensure optimal performance over extended periods.

What are the compatible communication protocols of the Allen-Bradley 2198-H025-ERS?

The Allen-Bradley 2198-H025-ERS is compatible with Ethernet/IP, facilitating smooth communication with CompactLogix, ControlLogix, and GuardLogix controllers.

How does the Allen-Bradley 2198-H025-ERS handle different power demands in industrial applications?

The servo drive 2198-H025-ERS demonstrates remarkable adaptability in power delivery, ranging from 4.0 kW to 8.3 kW. This variability is contingent upon the specific input voltage supply, allowing users to scale the power output based on the unique energy requirements of different automation systems.

Product Specifications Table

Attribute	Specifications
Series	Kinetix 5500
Horsepower	5.4- 11.1 HP
Voltage	240VAC
Dimensions	2.16 x 8.90 x 10.43 inches
Communication Interface	Ethernet/IP
Software Compatibility	Studio 5000 Logix Designer
Ambient Temperature Range	0 to 40 °C (32 to 104 °F)
Control Method	V/F control
Input/Output Frequency Range	Input: 48 to 63 Hz and Output: 0 to 240 Hz
Mounting Type	Panel Mount
