The Allen-Bradley 2198-P031 is a type of DC bus power supply product of an eminent company named Allen-Bradley. This DC power supply bus belongs to the series of Kinetix 5700 drive modules and is very beneficial in engineering and industrial usage. It provides high-speed processing and precision control, which is important for demanding motion control and its complex tasks.

Technical Specifications :

This type of power supply bus is a three-phase with a nominal AC input voltage from 230V to 480V and an output voltage from 276V to 747V. The power supply bus contains a 47 to 63 Hz frequency range for proper working. This power supply bus has a main AC input current with a value of 11.2A and a varying uninterrupted power from 3.5kW to 7kW. It holds a great percentage of efficiency at 99% for operating.

The Allen-Bradley 2198-P031 bus can bear an overvoltage of 460 to 832V DC, above this range, it can damage equipment. Another remarkable feature of this type of power supply bus is internal shunt resistance of 37.5 ohms and shunt power of 75W which assists to prevent high voltage. This power bus carries 129 Joules of capacitive energy absorption. Its control power DC input current is given by 0.8 A. Moreover, the high power density 2198-P031 means that sufficient power can be delivered from a tiny device, which is fit for use in applications where space is restricted but requires high working.

Operational and Installation Parameters:

Installation of Allen-Bradley 2198-P031 power bus requires a temperature range from 0 to 50°C (32-122 °F) for operating correctly. It weighs about 4.33 Kg and needs almost 10mm strip length. Furthermore, it has a torque value of 0.5 to 0.8 Nm for the wire requirement. Wire should be copper with a minimum temperature of 75 ?C (167 ?F). It can be mounted anywhere along a cluster with panel space. The phasing of mains AC power is random, and an earth-ground connection is one of the major needs for proper operation.

Safety Precautions:

In order to prevent overheating and device power failure make sure to not exceed the power bus rated capacity. It is also an important factor to keep the ground-screw access door closed when the power is on. And if the power is turned off, wait at least few minutes around 4 to 5 for the DC-bus voltage to vanish, and monitor that there is no voltage present before opening the ground screw access.

Wiring of the contactor-enable relay is also needed as a safety. Before operating the bus, check the connections and voltage requirements. Ground-shielded power cables are also used to protect from high voltages on the shield.

Frequently Asked Questions:

What are the input and output voltage specifications for the Allen-Bradley 2198-P031 DC bus power supply?

The Allen-Bradley 2198-P031 operates with a nominal AC input voltage range of 230V to 480V and provides an output voltage ranging from 276V to 747V. It supports a three-phase input and operates at a frequency range of 47 to 63 Hz.

What are the installation requirements for the Allen-Bradley 2198-P031 DC bus power supply?

It weighs 4.33 kg, needs a strip length of 10mm, and requires a torque value of 0.5 to 0.8 Nm for wiring, along with a random mains AC phasing and a secure earth-ground connection.

In what position can the 2198-P031 bus module be mounted?

The Kinetix 5700 Allen-Bradley 2198-P031 bus can be mounted only in an upright position and not to be mounted on its side. The installation must be performed by a trained professional.

Product Specifications Table

Attribute Specifications
Manufacturer Allen Bradley
Series Kinetix 5700
Input Voltage (AC) 230V - 480V
Output Voltage (AC) 276-747V
Strip length 10 mm
Weight (Kg) 4.33
Ambient Temperature Range 0-55 C
AC input Current (A) 11.2
AC Input Frequency Range 47-63Hz Hz
Internal shunt resistance (ohm) 37.5
