Allen-Bradley 2198-P141
Allen-Bradley 2198-P141
The Allen-Bradley 2198-P141 is an important product of Kinetix series 5700 from Allen Bradley, a brand of industrial automation products and software owned by Rockwell. This power bus works efficiently for accurate motion control and conversion applications.
Technical Specifications :
The Allen-Bradley 2198-P141 is engineered to handle an AC input current of 46.9 A, with a peak inrush current capacity of 33 A. During this process, it supports a peak input current of up to 148.7 A, using an input AC frequency limiting around 47 to 63 Hz.
It has a three-phase 324-528V (480V nominal) RMS AC input voltage and a module width of 85mm. It can deliver continuous power output within the range of 15kW to 31kW. Moreover, the time duration needed for the peak output current is 1 second for this power bus. This power bus also carries a nominal output voltage value of 276 to 747V DC. Its simplest and unique design configuration makes it the best choice among the machines for efficient working in electronic systems as well.
The bus contains other exceptional internal shunt power and resistance parameters as its internal shunt resistance is 13.5? which is found very proficient in case of shielding against high voltage and current issues. This bus also has an internal shunt power having power rating as 200W. It has a remarkable efficiency of almost 99% which helps to enhance its demand in industries.
Operational and Installation Parameters:
The 2198-P141 power supply bus has an innovative system that doesn't need any tools and can be assembled and installed in the drive. It weighs 15.2 lbs with dimensions of 9.29 x 3.35 x 17.04 in. However, multiple power supply modules can be installed to increase the output power of the bus. This bus can be installed at 0 to 50 degrees centigrade in a clean and dust-free environment. Also, it is important to ensure proper ventilation and cooling, which are two of the major requirements for installation.
Safety Measures:
It is important to use only suitable tools as specified in the installation manual, to avoid damage of the module. Ensure that device should be kept under the required temperature and it is recommended that a trained and professional person should install and operate the 2198-P141 power supply. For the Allen-Bradley 2198-P141, grounding of connections is needed to avoid any overvoltage and current problems along with its inbuilt safety features that work via Ethernet/IP network. Maintain proper emergency procedures and assistance in case of electrical shock or other hazards
Frequently Asked Questions:
What is the required internal shunt resistance of power bus 2198-P141?
The required internal shunt resistance of the power bus 2198-P141 is 13.5 ohms. This internal shunt resistance is essential as it helps to shield against overvoltage, ensuring the device operates safely and reliably.
What values of AC input frequency are needed for the 2198-P141 bus?
The Allen-Bradley 2198-P141 bus requires an AC input frequency in the range of 47 to 63 Hz for appropriate and reliable operation. Maintaining this frequency range is crucial to ensure the performance and longevity of the bus.
What are the output current specifications for the power bus 2948-P141?
The power bus 2198-P141 has an output current specification of 46.9A for consistent operation. Additionally, it has a peak output current rating of 140.8A, which allows it to handle short-term surges in current demand.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Manufacturer | Allen Bradley |
| Series | Kinetix 5700 |
| Input Voltage (AC) | 324V - 528V |
| Output Voltage (AC) | 276-747V |
| Internal Shunt power (W) | 200 |
| Weight (Kg) | 6.8 |
| Ambient Temperature Range | 0-55 C |
| AC input Current (A) | 46.9 |
| AC Input Frequency Range | 47-63Hz Hz |
| Internal shunt resistance (ohm) | 13.5 |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2198-P141
The Allen-Bradley 2198-P141 is an important product of Kinetix series 5700 from Allen Bradley, a brand of industrial automation products and software owned by Rockwell. This power bus works efficiently for accurate motion control and conversion applications.
Technical Specifications :
The Allen-Bradley 2198-P141 is engineered to handle an AC input current of 46.9 A, with a peak inrush current capacity of 33 A. During this process, it supports a peak input current of up to 148.7 A, using an input AC frequency limiting around 47 to 63 Hz.
It has a three-phase 324-528V (480V nominal) RMS AC input voltage and a module width of 85mm. It can deliver continuous power output within the range of 15kW to 31kW. Moreover, the time duration needed for the peak output current is 1 second for this power bus. This power bus also carries a nominal output voltage value of 276 to 747V DC. Its simplest and unique design configuration makes it the best choice among the machines for efficient working in electronic systems as well.
The bus contains other exceptional internal shunt power and resistance parameters as its internal shunt resistance is 13.5? which is found very proficient in case of shielding against high voltage and current issues. This bus also has an internal shunt power having power rating as 200W. It has a remarkable efficiency of almost 99% which helps to enhance its demand in industries.
Operational and Installation Parameters:
The 2198-P141 power supply bus has an innovative system that doesn't need any tools and can be assembled and installed in the drive. It weighs 15.2 lbs with dimensions of 9.29 x 3.35 x 17.04 in. However, multiple power supply modules can be installed to increase the output power of the bus. This bus can be installed at 0 to 50 degrees centigrade in a clean and dust-free environment. Also, it is important to ensure proper ventilation and cooling, which are two of the major requirements for installation.
Safety Measures:
It is important to use only suitable tools as specified in the installation manual, to avoid damage of the module. Ensure that device should be kept under the required temperature and it is recommended that a trained and professional person should install and operate the 2198-P141 power supply. For the Allen-Bradley 2198-P141, grounding of connections is needed to avoid any overvoltage and current problems along with its inbuilt safety features that work via Ethernet/IP network. Maintain proper emergency procedures and assistance in case of electrical shock or other hazards
Frequently Asked Questions:
What is the required internal shunt resistance of power bus 2198-P141?
The required internal shunt resistance of the power bus 2198-P141 is 13.5 ohms. This internal shunt resistance is essential as it helps to shield against overvoltage, ensuring the device operates safely and reliably.
What values of AC input frequency are needed for the 2198-P141 bus?
The Allen-Bradley 2198-P141 bus requires an AC input frequency in the range of 47 to 63 Hz for appropriate and reliable operation. Maintaining this frequency range is crucial to ensure the performance and longevity of the bus.
What are the output current specifications for the power bus 2948-P141?
The power bus 2198-P141 has an output current specification of 46.9A for consistent operation. Additionally, it has a peak output current rating of 140.8A, which allows it to handle short-term surges in current demand.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Manufacturer | Allen Bradley |
| Series | Kinetix 5700 |
| Input Voltage (AC) | 324V - 528V |
| Output Voltage (AC) | 276-747V |
| Internal Shunt power (W) | 200 |
| Weight (Kg) | 6.8 |
| Ambient Temperature Range | 0-55 C |
| AC input Current (A) | 46.9 |
| AC Input Frequency Range | 47-63Hz Hz |
| Internal shunt resistance (ohm) | 13.5 |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
