Allen-Bradley 2711-T10C8
The Allen-Bradley 2711-T10C8 is an advanced operator interface terminal developed for automation applications. This device, a member of the esteemed Allen-Bradley PanelView 1000 series, combines high functionality with robust features to enable effective process control and monitoring.
Technical Specifications:
The Allen-Bradley 2711-T10C8 operates at 47 to 63 Hz and 85 to 264V AC on a 100-240 VAC power source. This broad voltage range ensures compatibility with industrial power systems and operating flexibility. Designed for industrial use, the 2711-T10C8 performs well at 0 to 55 °C (32 to 131 °F). It can also tolerate 2 g vibrations and 15 g shocks at frequencies above 2,000 Hz. Its endurance makes it suitable for harsh conditions that require robustness and stability.
The terminal has two communication ports, Data Highway Plus (DH+) and RS232, for printer connections. Additionally, it boasts a responsive touch input system. These interfaces allow the industrial network to seamlessly exchange data and communication, integrating peripheral devices and boosting system compatibility.
The device is equipped with a significant amount of application memory, which includes 1008K bytes for application displays and an additional 310 kilobytes for application runtime memory. It is compatible with ATA flash memory devices for external memory storage.
The 2711-T10C8 is intended to be comparatively lightweight to facilitate installation, with a weight of 7 to 8 pounds (3.2 to 3.6 kilograms). It is compact enough to fit into various settings without occupying excessive space, with dimensions of approximately 11.11 x 14.58 x 4.40 inches.
Mounting:
The Allen-Bradley 2711-T10C8 is intended to mount flush to an enclosure and is exclusively compatible with horizontal orientation. To guarantee sufficient working space and ample airflow, a mounting clearance of 51 mm (2 inches) is necessary on all sides for proper installation.
Display Specifications:
The 2711-T10C8s display is designed to be both durable and clear, with a resolution of 640 x 480 pixels. It guarantees long-term visibility and dependability by employing LED illumination with an impressive life expectancy of 100,000 hours. The touchscreen capability comprises 384 touch cells, each measuring 26 x 30 pixels, and is arrayed in a 24-column by 16-row configuration. This precision touch input enables users to interact with the system precisely.
The display area is 211 x 158 mm (8.3 x 6.2 inches), sufficient for presenting intricate graphical representations. An Active Matrix Thin-Film Resistor (TFT) with a Cold Cathode Fluorescent (CCF) Backlight is implemented in the terminal to guarantee a multi-color, vibrant display. 10.1-inch screens are symmetrical, making them suitable for industrial applications that require detailed visual data.
Frequently Asked Questions:
In what ways does the Allen-Bradley 2711-T10C8 improve operational efficacy in industrial settings?
The 2711-T10C8 boasts a responsive touchscreen interface and a high-resolution 640 x 480-pixel display. These components enhance operational efficiency and user interaction by offering intuitive control and clear visuals.
The Allen-Bradley 2711-T10C8 is equipped to manage electrical fluctuations by implementing what measures?
The 2711-T10C8 can operate within an input voltage range of 85 to 264V AC and is compatible with frequencies ranging from 47 to 63 Hz. Even in environments with electrical fluctuations, this extensive spectrum guarantees consistent performance.
What memory capabilities does the Allen-Bradley 2711-T10C8 provide for intricate applications?
The 2711-T10C8 comprises 310 kilobytes of operational memory and 1008K bytes of application memory. Furthermore, it can accommodate complex and extensive application data by supporting ATA flash memory devices for external storage.
Product Specifications Table:
| Attributes |
Specification |
| Input Voltage Range |
85 to 264V AC |
| Communication Ports |
Data Highway Plus (DH+); RS232 (printer) |
| Application Memory |
1008K bytes (application screens) |
| Runtime Memory |
310 kilobytes |
| Display Resolution |
640 x 480 pixels |
| Backlight Life |
100,000 hours |
| Touchscreen Configuration |
24 columns x 16 rows |
| Display Area |
211 x 158 mm (8.3 x 6.2 in.) |
| Display Type |
Active Matrix TFT with CCF Backlight |
| Weight |
7-8 pounds (3.2 to 3.6 kilograms) |
