Allen-Bradley 2711P-T10C22D9P

Allen-Bradley 2711P-T10C22D9P

SKU: 2711P-T10C22D9P-FS
We have 24 in stock
$3,995.00
$3,995.00
the lowest price in the last 30 days
See product description

Estimated delivery:

- +
More payment options
Eligible for Next Day Delivery Order before 4 PM ET for same-day processing. More about shipping
All Parts Come with 24 Month Warranty Industry-leading protection for your purchase. More about warranty
New, Refurbished and Repairs Available Multiple options to meet your needs and budget

Secure payment options

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.


  • 2711PT10C22D9P
  • OPERATOR INTERFACE
  • TOUCH SCREEN
  • PANELVIEW PLUS 7
  • PERFORMANCE
  • COLOR TERMINAL
  • 10.4 INCH
  • STANDARD COMMUNICATION: ETHERNET AND RS-232
  • 512 MB NONVOLATILE MEMORY
  • 512 MB RAM
  • DC POWER

Getting to Know the Allen Bradley 2711P-T10C22D9P Operator Interface

A member of the PanelView Plus 7 Product line, the Allen Bradley 2711P-T10C22D9P operator interface is a touchscreen PanelView performance operator. The module contains an 800 × 600 SVGA color TFT screen with an 18-bit resolution. This display's steady, white-light LED backlighting has an approximate 50,000-hour lifespan and cannot be replaced.

Allen Bradley 2711P-T10C22D9P operator interface

2711P-T10C22D9P Key Features and Benefits

The module provides external memory via a single card cover compatible with 1784-SDx SD cards. It also includes Dual 10/100 Base-T DLR Ethernet interfaces. The module runs on Windows CE, which has a variety of Office software readers and added capabilities.

Other features include:

  • FactoryTalk ViewPoint operating system, edition 2.6+
  • 10.4-inch high-resolution display screen
  • 80 MB of storage for nonvolatile programs
  • 512 MB of storage and user memory
  • Power terminal blocks
  • Battery replacements

Allen Bradley 2711P-T10C22D9P Technical Specifications

The Allen-Bradley 2711P-T10C22D9P uses 50 watts of electricity and supports PELV and SELV 24-volt DC sources. It has several certifications, such as CE (LVD), ATEX Zone 2, and the basic EAC.

Other technical specifications include:

  • Nominal DC supply voltage: 24 volts
  • Dimensions: 9.92 by 11.69 by 2.74 inches
  • Weight: 5.03 lbs.

Applications

The Allen Bradley 2711P-T10C22D9P operator interface is a digitalized module that sends network commands to other devices. Its terminal functionality allows connection to one controller, up to 100 screens, and as many as 500 alarms.

An upgraded version of the Windows-based OS is included. In addition to fundamental functionality like File Transfer Protocol (FTP), remote access via VNC, PDF file compliance, and Active-X controls, this enhanced version also features a Microsoft Office file reader & Windows Media player. The FactoryTalk View Machine Version running time, which offers the runtime environment for the downloaded program, is also already installed. Applications created with FactoryTalk View Machine or Site Version Studio are supported.

Allen-Bradley 2711P-T10C22D9P

Extensive Ethernet Capabilities With the 2711P-T10C22D9P

The module's two Ethernet ports link the system to the industry level and integrate controllers onto the factory floor. The topologies for these Ethernet ports are ring, star, and linear. The maximum distance available with Ethernet is 100 meters; however, this distance can be easily increased with Ethernet switches or optic fiber converters.

FAST SHIPPING & EXCELLENT CUSTOMER SERVICE

Order Now from Industrial Automation Co.

Industrial Automation Co. is the go-to spare parts supplier like the Allen Bradley 2711P-T10C22D9P operator interface. We support all our sales with outstanding customer service and quick turnarounds. You can rely on this module from Industrial Automation Co. to provide all the functionality and performance you expect from Allen Bradley products. Purchase yours today!
