Allen-Bradley 440C-CR30-22BBB

The Allen-Bradley 440C-CR30-22BBB is a versatile software-configurable safety relay engineered for integration into the safety-related control systems of industrial machines.

It stands as a comprehensive solution for enhancing industrial machine safety. With its robust design, extensive safety features, and intuitive configurability, it not only safeguards personnel and equipment but also supports operational efficiency and regulatory compliance.

Technical Specifications:

The Allen-Bradley 440C-CR30-22BBB combines robust construction with advanced safety features, making it a standout choice for integrating into the safety-related control systems of industrial machines.

Designed to adhere to the highest safety standards, it boasts a Performance Level (PL) of PLe and a Safety Integrity Level (SIL) of SIL 3, ensuring reliable operation in safety-critical applications. It supports up to 22 safety input/output (I/O) points, accommodating various safety monitoring functions such as single-channel, dual-channel, and safety outputs.

Additionally, the relay supports single-wire safety configurations, providing versatility in wiring installations. Comprehensive documentation and wiring diagrams accompany the product, ensuring correct setup and adherence to safety standards such as ISO 13849-1:2015 and IEC 62061:2005.

Wiring and Installation Guidelines:

The Allen-Bradley 440C-CR30-22BBB is engineered for straightforward installation and reliable operation within industrial safety systems. Its compact DIN-rail mountable design facilitates flexible placement in control panels and cabinets, optimizing space utilization in diverse manufacturing environments.

During the installation process, ensure that the environment surrounding the relay is conducive to safe and efficient operation. The unit is designed to withstand typical industrial conditions, but avoiding locations prone to excessive vibration, moisture, or temperature extremes that could affect performance is essential.

The wiring configuration of the Allen-Bradley 440C-CR30-22BBB supports a variety of safety input and output options. For single-channel inputs, connect the appropriate signal wires according to the specified terminals on the relay.

Dual-channel inputs require careful wiring to ensure redundancy and reliability in safety monitoring functions. Safety outputs are similarly wired to control external safety devices or signals, enhancing the overall safety integrity of the machine.

Single-wire safety configurations offer flexibility in wiring installations, streamlining the connection of safety devices while maintaining safety performance. Throughout the installation process, attention to detail is crucial to prevent wiring errors and ensure the relay operates as intended.

Programming and Configuration:

Configuration of the Allen-Bradley 440C-CR30-22BBB is facilitated through the use of Allen-Bradleys Connected Components Workbench software. This software platform allows operators and engineers to tailor safety monitoring functions, logic operations, and safety outputs to meet the specific requirements of their machine safety systems.

By leveraging this software, users can implement precise safety protocols and ensure compliance with stringent safety standards. Regarding communication capabilities, the Allen-Bradley 440C-CR30-22BBB supports the Modbus communication protocol.

This feature enables seamless integration with supervisory control systems, providing real-time status monitoring and enabling remote diagnostics and troubleshooting. Operators can read relay status and issue reset commands effectively, enhancing operational efficiency and minimizing downtime during maintenance procedures.

Frequently Asked Questions:

What are muting options in the Allen-Bradley 440C-CR30-22BBB, and when are they used?

Safety functions supported by the Allen-Bradley 440C-CR30-22BBB include muting options for both 2-sensor L-type and 4-sensor T-type bidirectional setups, catering to applications where temporary suspension of safety functions is necessary.

What international standards does the Allen-Bradley 440C-CR30-22BBB meet?

Certified to meet stringent international standards, including EN 60204-1:2018 and EN ISO 13850:2015, the 440C-CR30-22BBB ensures compliance with regulatory requirements across global markets.

What is the operating temperature range of the Allen-Bradley 440C-CR30-22BBB?

The operating temperature range of the Allen-Bradley 440C-CR30-22BBB safety relay extends up to 131°F (55°C). Operating within this temperature range is crucial for ensuring the safety relay functions optimally in various industrial environments.

Product Specifications Table
