- 5069IB16
- I/O MODULE
- COMPACTLOGIX
- 16 CHANNEL
- 24 VOLT DC
- SINK INPUT
- RACK MOUNT
Understanding the Allen-Bradley 5069-IB16 I/O Module
The Allen-Bradley 5069-IB16 is an I/O module that is part of the Compact 5000™ I/O modules lineup. These modules provide high-performance control in a compact design, expanding the performance capabilities of the Logix platform. They can be used as local I/O modules in a CompactLogix™ 5380, Compact GuardLogix® 5380, or CompactLogix 5480 system. Safety options are also available. These modules are excellent distributed I/O solutions for various controllers on an EtherNet/IP network, especially in scenarios involving safety module restrictions. They are particularly suitable for applications with high-processing requirements.
Key Features and Benefits
- 16 Channel Input: High degree of versatility​
- High-Performance Control: A compact design that expands the performance capabilities of the Logix platform
- Integration with Multiple Systems: An ideal distributed I/O solution on an EtherNet/IP network for CompactLogix 5380, Compact GuardLogix 5380, CompactLogix 5480, ControlLogix 5580, and GuardLogix 5580 controllers with safety module restrictions​
- Ideal for High-Processing Applications: Great for applications with high-processing requirements
- Mounting Type: Designed for Chassis mounting, offering flexibility in installation
Technical Specifications
The 5069-IB16 module has the following specs:
- 16 channels
- 24V DC
- Sink input type
- Requires Terminal Kits 5069-RTB18-Screw/Spring
- Chassis mounting type
Allen-Bradley 5069-IB16 Applications
Thanks to its 16-channel input and high-performance capabilities, the 5069-IB16 is suited for a broad range of applications:
- Process Control Systems: The module can be used in control systems that regulate processes in various industrial sectors. These include automation systems in manufacturing, chemical, petrochemical, and power generation facilities.
- Distributed I/O Systems: The 5069-IB16 is ideal for distributed I/O systems in automation environments. It can work with CompactLogix 5380, Compact GuardLogix 5380, CompactLogix 5480, ControlLogix 5580, and GuardLogix 5580 controllers, making it a versatile solution for complex automation systems.
- Safety Systems: Safety options are available, making them suitable for safety-related applications in industries where monitoring and control are crucial.
- High-Processing Requirement Applications: Due to its high-performance control capabilities, the 5069-IB16 is ideal for applications with high-processing requirements like advanced manufacturing processes, testing and measurement systems, and real-time control systems.
Installation and Configuration
- Mounting: The 5069-IB16 is designed for chassis mounting. Choose a suitable location that provides adequate space and ventilation for the module.
- Terminal Connection: The module requires using terminal kits for connection. Compatible terminal kits include the 5069-RTB18-Screw/Spring. Connect the wires to the terminal block by following the wiring diagram.
- Power Supply: Ensure a 24V DC power supply is connected correctly to the module. Always verify that the power is off before making or changing connections.
- Software Configuration: The module can be configured using the appropriate Allen-Bradley software, such as RSLogix 5000 or Studio 5000 Logix Designer. You can set up module properties, input ranges, and other necessary parameters.
- Network Configuration: The module being used in a network must be correctly configured within the network settings. This includes setting up the EtherNet/IP address, if applicable, and defining its role in the network.
- Safety Configuration: Additional configuration in the safety controller may be required if safety features are utilized. This may include defining safety zones, interlock conditions, or fail-safe states.
Always follow safety guidelines when installing and configuring any industrial automation equipment. Consult a qualified technician or the manufacturer's technical support if you need clarification on any steps.
