Allen-Bradley 5069-IF8

Allen-Bradley 5069-If8

Allen-Bradley 5069-IF8

Regular price
$961.00
Sale price
$961.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚ here.


  • 5069IF8
  • PLC MODULE
  • COMPACT 5000
  • ANALOG INPUT TYPE
  • 8 CHANNEL
  • CURRENT / VOLTAGE SENSING
  • RACK MOUNT

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 5069-IF8-FS $961.00 USD 2 Year Extended Warranty 1 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Allen-Bradley 5069-IF8 PLC Module Info

The Allen-Bradley 5069-IF8 is an active module that forms part of the Compact 5000™ I/O range, offering high-performance control in a compact design. It provides eight voltage/current analog input channels with configurable analog inputs for flexible use.

Allen-Bradley 5069-IF8

Core Features and Benefits

  • Configurable Analog Inputs: The 5069-IF8 has eight configurable analog inputs to adapt to diverse needs.
  • Voltage and Current Input Modes: The module supports voltage and current input modes, providing versatility in various application scenarios.
  • Active Lifecycle Status: It is currently manufactured and supported.
  • Compact Design: As part of the Compact 5000™ I/O range, the module provides high-performance control in a small package, making it ideal for installations where space is at a premium.

Allen-Bradley 5069-IF8 Technical Specifications

  • Number of Inputs: There are eight analog inputs.
  • Electric Connection Type: The module uses a screw-/spring clamp connection.
  • Input Range: The input range for current is between 0-20 mA and 4-20 mA.
  • Scan Time: The scan time per channel is 625 μs, and per group is 2.5 ms.
  • Step Response Time: The step response time to 63% of the value is 7.5 ms with a Notch filter at 10 kHz.
  • Module Conversion Method: The module conversion method uses Sigma-Delta, with two 24-bit multiplexed ADC.
  • Overvoltage Protection: The module offers overvoltage protection, with a maximum limit of ±30V DC in both voltage and current modes.
  • Common Mode Voltage: The common mode voltage is ±10V in current mode and ±2V in voltage mode.
  • Data Format: The module uses IEEE 32-bit floating point data format.
  • Wire Category: 2 - shielded input ports, 2 - power ports, and 1 wire per terminal for each signal port is supported.
  • Power Dissipation: The maximum power dissipation is 2.1 W in voltage mode and 2.4 W in current mode.
  • Indicators: The module has 1 green/red status indicator and 8 yellow/red I/O status indicators.
  • Thermal Dissipation: The maximum thermal dissipation is 7.2 BTU/hr in voltage mode and 8.2 BTU/hr in current mode.
  • Accuracy Drift with Temperature: The accuracy of drift with temperature is 0.20% full scale for voltage and 0.30% full scale for current.
  • Input Total Unadjusted Error (TUE): The Input Total Unadjusted Error (TUE) is 0.30% full scale for voltage and 0.40% full scale for current.
  • Wire Size: The module supports 0.5 - 1.5 mm² (22 - 16 AWG) solid or stranded copper wire that has been rated at 105 °C (221 °F) or higher, 2.9 mm (0.11 in.), max diameter (with insulation).
  • Calibrated Accuracy: The calibrated accuracy is 0.10% full scale @ 25 °C for both voltage and current.
  • Open Circuit Detection Time: The open circuit detection time is less than 2 seconds for both voltage and current modes.

Applications

The Allen-Bradley 5069-IF8 PLC Module finds extensive use in a wide variety of applications. Its versatile design and high-performance capabilities make it particularly suitable for scenarios requiring high-processing requirements. Some specific applications include:

  • Industrial Automation: With its eight configurable analog inputs, the 5069-IF8 is widely used in various industrial automation processes, where it helps control and monitor machinery and production lines.
  • Energy Management: In energy management systems, the module is often used to monitor and control various parameters such as voltage and current, helping to improve energy efficiency and reliability.
  • Process Control: In sectors like manufacturing, chemicals, and food and beverage, the 5069-IF8 assists in precise process control, ensuring high-quality results and operational efficiency.
5069-IF8

Installation and Configuration

Installing and configuring the Allen-Bradley 5069-IF8 PLC Module is straightforward due to its modular design and intuitive interface. It uses a screw-/spring clamp connection for installation, ensuring a secure fit. Configuration of analog inputs can be achieved through programming software, allowing for easy customization to meet the unique requirements of your specific application. Always ensure to follow the manufacturer's guidelines and safety procedures during the installation and configuration process.

Unmatched Customer Service & Shipping Standards

Get the Best With Industrial Automation Co.

Upgrade your automation system with the reliable and versatile Allen-Bradley 5069-IF8 PLC Module. Industrial Automation Co. strives to provide best-in-class products and services. We can assist with your selection, ensuring you find the perfect solution for your needs. Do not wait; elevate your operations to new heights of efficiency with Industrial Automation Co. today!

Shop 5069-IF8

TECHNICAL SPECIFICATIONS

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.5069-IF8
Module TypeAnalog Input
Number of Inputs8 Differential Inputs
Number of OutputsN/A
Voltage CategoryN/A
Input Voltage Range+/- 10 Volts, 0-10 Volts, 0-5 Volts
Output Voltage RangeN/A
Power Dissipation2.1 Voltage Mode and 2.4 Current Mode
Enclosure TypeNone (Open Style)
Dimensions5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm)
Weight0.39 lbs (175 g)
Pulse Latching SupportedYes
Pattern Matching SupportedYes
