Allen-Bradley 5069-OBV8S
Allen-Bradley 5069-OBV8S
The Allen-Bradley 5069-OBV8S is a robust and reliable component of the Compact 5000 I/O series. It stands out as a high-performance, safety-centric output module ideal for modern industrial applications.
Technical Specifications:
This digital 8-point Safety Sourcing Output Module features eight output channels, each operating within a voltage range of 17.5 to 32VDC and capable of delivering an output current of 1 A per channel. This capability ensures that the module can handle substantial electrical loads, making it suitable for a variety of demanding applications.
Safety is a paramount concern in the design of the Allen-Bradley 5069-OBV8S. It boasts a Safety Integrity Level (SIL) CL3 rating and complies with PLe and Category 4 standards, offering the highest levels of safety and reliability.
The Allen-Bradley 5069-OBV8S is engineered for durability and versatility. It has an isolation voltage rating of 250 volts, providing robust protection against electrical surges and ensuring the longevity of the module.
In terms of voltage protection, the module is equipped with reverse voltage protection, safeguarding the module from potential damage due to incorrect voltage polarity.
The module's design includes two output groups, allowing for flexible and organized wiring configurations. Each group can handle a minimum pulse width of 400 microseconds, ensuring accurate and reliable signal processing.
Physical Features:
Constructed with a conformal coating, the module is protected against environmental factors such as moisture, dust, and chemicals, enhancing its reliability and lifespan. The use of copper wire ensures optimal electrical conductivity and durability, further contributing to the module's robust performance.
The dimensions of the Allen-Bradley 5069-OBV8S are 144.57 mm (5.69 in.) in length, 22 mm (0.87 in.) in width, and 105.42 mm (4.15 in.) in height. These dimensions provide a clear understanding of the physical size of the component. The weight of the module is approximately 175 grams (0.39 pounds). This information is useful for determining the component's mass and handling requirements.
Maintenance and Safety Precautions:
Proper maintenance routines, coupled with stringent safety precautions, can prevent unexpected failures and enhance operational reliability. Firstly, regular visual inspections are essential. Inspect the module and its connections for any signs of physical damage, corrosion, or wear.
Ensuring that the connections are secure and free of dust or debris can prevent electrical issues and maintain consistent performance. Periodically check the integrity of the wiring, particularly looking for any signs of fraying or damage that could lead to shorts or open circuits.
Temperature management is another key aspect of maintenance. Ensuring that the module is not exposed to temperatures outside this range can prevent thermal stress and potential damage.
When performing any maintenance work on the Allen-Bradley 5069-OBV8S, it is crucial to follow lockout/tagout (LOTO) procedures to ensure the system is de-energized. This safety measure prevents accidental energization, which could lead to electrical shock or equipment damage.
Frequently Asked Questions:
What is the safety reaction time (SRT) of the Allen-Bradley 5069-OBV8S?
The module's safety reaction time (SRT) is an impressive 4.5 milliseconds, which facilitates rapid response to potential safety breaches.
What is the nominal output voltage of the Allen-Bradley 5069-OBV8S?
The nominal output voltage of Allen-Bradley 5069-OBV8S is 24VDC, which is important because it aligns with standard industrial power supplies, ensuring compatibility and efficient integration into existing systems.
What is the operating temperature range of the Allen-Bradley 5069-OBV8S?
The Allen-Bradley 5069-OBV8S can operate within a temperature range of 0 to 50 degrees Celsius. It ensures reliable performance even under demanding conditions, while its compact form factor allows for easy integration into existing systems.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Compact 5000 I/O series |
| Voltage | 17.5 to 32VDC |
| Dimensions | 144.57 x 22 x 105.42 mm |
| Communication Interface | Ethernet/IP devices |
| Software Compatibility | Studio 5000 Logix |
| Nominal output voltage | 24 VDC |
| Operating Temperature range | 0-50 ? |
| Weight | 0.39 pounds |
| Mounting type | DIN rail |
| Product Status | Active |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 5069-OBV8S
The Allen-Bradley 5069-OBV8S is a robust and reliable component of the Compact 5000 I/O series. It stands out as a high-performance, safety-centric output module ideal for modern industrial applications.
Technical Specifications:
This digital 8-point Safety Sourcing Output Module features eight output channels, each operating within a voltage range of 17.5 to 32VDC and capable of delivering an output current of 1 A per channel. This capability ensures that the module can handle substantial electrical loads, making it suitable for a variety of demanding applications.
Safety is a paramount concern in the design of the Allen-Bradley 5069-OBV8S. It boasts a Safety Integrity Level (SIL) CL3 rating and complies with PLe and Category 4 standards, offering the highest levels of safety and reliability.
The Allen-Bradley 5069-OBV8S is engineered for durability and versatility. It has an isolation voltage rating of 250 volts, providing robust protection against electrical surges and ensuring the longevity of the module.
In terms of voltage protection, the module is equipped with reverse voltage protection, safeguarding the module from potential damage due to incorrect voltage polarity.
The module's design includes two output groups, allowing for flexible and organized wiring configurations. Each group can handle a minimum pulse width of 400 microseconds, ensuring accurate and reliable signal processing.
Physical Features:
Constructed with a conformal coating, the module is protected against environmental factors such as moisture, dust, and chemicals, enhancing its reliability and lifespan. The use of copper wire ensures optimal electrical conductivity and durability, further contributing to the module's robust performance.
The dimensions of the Allen-Bradley 5069-OBV8S are 144.57 mm (5.69 in.) in length, 22 mm (0.87 in.) in width, and 105.42 mm (4.15 in.) in height. These dimensions provide a clear understanding of the physical size of the component. The weight of the module is approximately 175 grams (0.39 pounds). This information is useful for determining the component's mass and handling requirements.
Maintenance and Safety Precautions:
Proper maintenance routines, coupled with stringent safety precautions, can prevent unexpected failures and enhance operational reliability. Firstly, regular visual inspections are essential. Inspect the module and its connections for any signs of physical damage, corrosion, or wear.
Ensuring that the connections are secure and free of dust or debris can prevent electrical issues and maintain consistent performance. Periodically check the integrity of the wiring, particularly looking for any signs of fraying or damage that could lead to shorts or open circuits.
Temperature management is another key aspect of maintenance. Ensuring that the module is not exposed to temperatures outside this range can prevent thermal stress and potential damage.
When performing any maintenance work on the Allen-Bradley 5069-OBV8S, it is crucial to follow lockout/tagout (LOTO) procedures to ensure the system is de-energized. This safety measure prevents accidental energization, which could lead to electrical shock or equipment damage.
Frequently Asked Questions:
What is the safety reaction time (SRT) of the Allen-Bradley 5069-OBV8S?
The module's safety reaction time (SRT) is an impressive 4.5 milliseconds, which facilitates rapid response to potential safety breaches.
What is the nominal output voltage of the Allen-Bradley 5069-OBV8S?
The nominal output voltage of Allen-Bradley 5069-OBV8S is 24VDC, which is important because it aligns with standard industrial power supplies, ensuring compatibility and efficient integration into existing systems.
What is the operating temperature range of the Allen-Bradley 5069-OBV8S?
The Allen-Bradley 5069-OBV8S can operate within a temperature range of 0 to 50 degrees Celsius. It ensures reliable performance even under demanding conditions, while its compact form factor allows for easy integration into existing systems.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Compact 5000 I/O series |
| Voltage | 17.5 to 32VDC |
| Dimensions | 144.57 x 22 x 105.42 mm |
| Communication Interface | Ethernet/IP devices |
| Software Compatibility | Studio 5000 Logix |
| Nominal output voltage | 24 VDC |
| Operating Temperature range | 0-50 ? |
| Weight | 0.39 pounds |
| Mounting type | DIN rail |
| Product Status | Active |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Introduction
The Allen-Bradley 5069-OBV8S Safety Output Module represents a significant advance in the Compact 5000 series, offering tight integration with automation systems. This module comes with an 8 channel configuration, supporting 24VDC, crafted to optimize productivity in automation projects. Its design ensures reliable safety outputs critical in managing complex automation infrastructures.
Technical Specifications for Allen-Bradley 5069-OBV8S
The 5069-OBV8S module is part of the renowned Compact 5000 series, notorious for its efficiency and reliability. It operates on a 24 VDC power supply and is equipped with 8 safety output channels, enhancing its utility in varied automation landscapes. The module boasts a straightforward integration into existing setups, ensuring seamless operation and safety compliance.
Environmental Requirements for Installation and Operation
As with all electronic equipment, the Allen-Bradley 5069-OBV8S requires certain environmental conditions to operate optimally. While the equipment is robust, ensuring a clean, dust-free, and adequately ventilated environment will prolong its life and maintain its performance. It's also crucial to keep the module away from direct sunlight and moisture to prevent any potential damage.
Parts and Compatibility
Intended for use with other components in the Compact 5000 series, this module ensures a high level of compatibility and integration within Allen Bradley's product range. It comes ready for installation with necessary connectors, ensuring a quick setup process. Users will find leveraging its features straightforward, with detailed guidance available for complex setups or integration needs.
Advanced Protective Measures
The 5069-OBV8S module includes several built-in protective features designed to safeguard against electrical faults, overcurrent, and unexpected operating conditions. These safety functions are critical in minimizing downtime and maintaining operational continuity, which is essential in high-stakes automation environments.
Ready to Enhance Your System?
Optimize your automation setup with the Allen Bradley 5069-OBV8S today. Ensure superior performance and safety with our products.
