Belden ProSoft MVI69-GSC
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Belden ProSoft MVI69-GSC
The Belden ProSoft MVI69-GSC is a powerful communication module that boosts connectivity in industrial automation systems. Bridging various communication protocols enables smooth data exchange between different devices. Known for its reliability and user-friendly design, the MVI69-GSC ensures efficient operation of complex industrial processes, making it essential for modern automation.
Technical Features:
The MVI69-GSC, a single-slot module compatible with the 1769 backplane, integrates effortlessly into existing systems. Functioning as an Input/Output module, it facilitates efficient data transfer between the processor and module, ensuring crucial information is readily accessible for system operations.
Data transfer between the module memory and processor controller tags is handled using Ladder Logic, a common programming method in industrial automation. This simplifies integration and boosts the module's functionality.
Configuring the MVI69-GSC is easy with a downloadable configuration text file that contains all necessary data. A sample file is included to guide users through the setup, enabling quick and accurate module configuration to meet specific requirements.
The MVI69-GSC is compatible with various controllers, such as CompactLogix and MicroLogix 1500 LRP, providing flexible application options. However, it does not support the 1769-QBFC1B, 1769-L16x, and 1769-L18x models. This compatibility broadens its use in different industrial environments, enhancing its versatility and utility.
The MVI69-GSC, part of the MVI69 series, requires an 800mA power supply at 5 volts and must be placed within two slots of the power source. This setup ensures the module receives sufficient power and is optimally positioned for efficient operation.
All MVI modules, including the MVI69-GSC, have negligible 24-volt requirements, ensuring they do not significantly burden the system's power supply. This feature enhances these modules' overall efficiency and reliability within the broader automation setup.
Operating Conditions:
The Belden ProSoft MVI69-GSC module is built to thrive in various industrial environments. It can operate seamlessly in temperatures from 32°F to 140°F (0°C to 60°C), making it adaptable to both cool and warm settings.
The MVI69-GSC handles humidity well, operating effectively in relative humidity levels from 5% to 95%, provided no condensation exists. This capability ensures reliable functioning in environments with varying moisture levels, from dry to high humidity.
Installation Guidelines for MVI69-GSC:
To install the Belden ProSoft MVI69-GSC module, power down the CompactLogix or MicroLogix 1500 LRP controller and ensure a static-free environment. Insert the module into an appropriate slot in the 1769 backplane and secure it with the mounting screws.
Power up the controller, and the module should appear in the I/O configuration. Use the provided configuration text file to set the module parameters and download it using the necessary software tools.
Configure the Ladder Logic in your PLC program using the included sample ladder file and Add-On Instructions (AOI) to handle data transfer between the module memory and processor controller tags.
Frequently Asked Questions:
What do the LED indicators on the MVI69-GSC module signify?
The LED indicators on the MVI69-GSC module provide information about battery and module status, application status, and port activity. These LEDs indicate the module's overall health and operational status.
What types of communication ports are available on the MVI69-GSC module?
The MVI69-GSC module includes a CFG port with an RJ45 connector for RS-232 communication (no hardware handshaking) and two application ports (P1 and P2) configurable for RS-232, RS-485, or RS-422 via jumpers.
How is the MVI69-GSC module isolated from the backplane, and what are the benefits?
The MVI69-GSC module offers 500V optical isolation from the backplane, protecting against electrical noise and transients from the serial communication ports and ensuring they do not affect the backplane or other modules.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | MVI69 |
| Load Rating | 800 mA @ 5 VDC |
| Dimensions | Single-slot, 1769 backplane compatible |
| Mounting Type | ControlLogix/MicroLogix chassis |
| Control Method | ProSoft Configuration Builder (PCB) software for configuration and diagnostics |
| Ambient Temperature Range | 0°C to 60°C (32°F to 140°F) |
| Optical Isolation | 500 V |
| Communication Interface | 1 x RS-232 Serial Configuration Port (CFG, RJ45), 2 x RS-232/422/485 Serial Communication Ports (P1/P2, RJ45) |
| Weight | 1.00 lbs (0.45 kg) |
| Baud rate | 110 to 115.2K baud |
