Beijer Electronics Exter-T100
The Beijer Electronics Exter-T100 is a versatile 10-inch graphic touch HMI panel built for industrial use. Its rugged IP66-rated front enclosure makes it reliable in tough conditions, including high-pressure washing and dust and water exposure.
Specifications of Beijer Electronics Exter-T100:
The Beijer Electronics Exter-T100 is a durable and adaptable HMI panel tailored for diverse industrial needs. It boasts a 10.4-inch TFT display with an 800 x 600-pixel resolution, delivering clear and detailed visuals. The Exter-T100 has a 350 cd/m² CCFL backlit display with a 50,000-hour lifespan and a resistive touch screen that withstands up to one million touches. It features an IP66-rated front panel for dust and water protection and an IP20-rated rear panel to safeguard internal components.
The Exter-T100 offers extensive connectivity with multiple communication ports: a 9-pin DSUB and a 25-pin DSUB serial port supporting RS232, RS422, and RS485 protocols, plus an Ethernet port supporting 10/100 Base-T communication. These options ensure seamless integration into various industrial networks and systems.
The panel operates on a 20-30 VDC input, with a maximum power consumption of 12 W, and includes an internal DC fuse for protection. Its housing, made from powder-coated aluminum, is lightweight yet durable, with the unit weighing around 2.1 kg.
The Exter-T100 is configured with Beijer's Information Designer software, making HMI setup and management straightforward. This tool enhances the panel's ability to display and control text, dynamic indicators, alarms, and recipes, offering a comprehensive solution for industrial automation.
Ambient Conditions:
The Beijer Electronics Exter-T100 is built for reliability in diverse industrial environments. This equipment operates optimally within an ambient temperature range of up to 40°C when mounted horizontally and up to 50°C vertically, offering versatile installation options to suit various conditions.
Humidity is another key factor, and the Exter-T100 operates effectively in environments with relative humidity levels up to 85%. This ensures reliable performance in both dry and moderately humid conditions.
Industrial Applications:
The Beijer Electronics Exter-T100 is a versatile HMI panel for industrial automation, providing robust monitoring and control. The Exter-T100 oversees manufacturing production lines, ensuring efficient and precise equipment operation.
The Exter-T100 is also extensively used in the energy sector, especially for managing renewable energy sources like wind and solar farms. Its durable construction ensures reliable performance in outdoor installations, offering real-time data and control capabilities to optimize energy production and distribution.
In the marine and transportation industries, the Exter-T100's robust design ensures reliable performance under challenging conditions, including exposure to saltwater and vibrations. It is used in shipboard systems and transportation hubs to manage complex logistics and ensure the smooth operation of critical infrastructure.
Frequently Asked Questions:
What is the project storage capacity of the Exter-T100 and how does it impact the device's functionality?
The Beijer Electronics Exter-T100 has a 12 MB project storage capacity for HMI files, including graphical interfaces, control scripts, and data logging. This ample storage supports complex HMI projects.
What type of display does the Exter-T100 use, and what are its benefits?
The Exter-T100 features a TFT display with CCFL backlighting, offering high-quality color reproduction and sharp image clarity. The CCFL backlight provides consistent brightness and a long lifespan, ensuring reliable performance for detailed industrial graphical interfaces.
What is the expected lifespan of the Exter-T100's backlight, and how does it affect maintenance schedules?
The Exter-T100's backlight lasts 50,000 hours, reducing maintenance and operational costs. Its extended lifespan ensures reliable performance in continuous operation industries, minimizing downtime and interruptions.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Product Type | HMI Panel |
| Voltage | 20 - 30 V DC |
| Dimensions | Front panel: 302 x 228 x 6 mm, Mounting depth: 58 mm (158 mm including clearance) |
| Mounting Type | Panel mount |
| Weight | 2.1 kg |
| Ambient Temperature Range | 0 to +50°C |
| Software Compatibility | Configured with Information Designer software tool |
| Communication Interface | 1x Ethernet 10/100 Base-T (shielded RJ45), 2x Serial ports (RS232/RS422/RS485) |
| Control Method | Touch screen |
| Resolution | 800 x 600 pixels |
