Indramat HCS01.1E-W0018-A-03

The Indramat HCS01.1E-W0018-A-03 is a drive controller in the Rexroth IndraDrive Cs series. It is a compact converter with a maximum Current of 18 A and a Mains Connection Voltage of 3 x AC 200 to 500 V + or -10 %.

Technical Description:

The Indramat HCS01.1E-W0018-A-03 is a compact designed, high-performance drive controller for industrial automation applications. It belongs to the IndraDrive Cs series of Rexroth, which is developed with high efficiency and is very flexible. This drive controller applies an input voltage of 200-240V AC, providing an output power of 1.8 kW. This drive controller has an operating current of 8 amperes with a peak current of 18 amperes and, therefore is appropriately more than capable of meeting more demanding requirements.

The HCS01.1E-W0018-A-03 drive controller is equipped with a digital control option and has various interfaces including the SERCOS III, EtherCAT and PROFINET, which makes it compatible with many kinds of control systems. Due to its compact design, it is easily installed in limited areas. In addition, the IP20 protection class is appropriate for its utilization in industrial conditions. The active temperature range of operation is between 0°C and +40°C, which makes it suitable for various environments.

This drive controller has effective usage in packaging machines, printing machines, textile machines and material handling systems and machines. Its control algorithms provide better energy usage management and reduce operating expenses. The software tools utilized in the implementation are very easy to set up and install and consequently have minimal downtime. The Indramat HCS01. The requirements of vehicle 1E-W0018-A-03 include reliability, flexibility, and high performance, meeting all the requirements, which is why it is suitable for different industries.

Attachments Specifications:

The Indramat HCS01.1E-W0018-A-03 drive controller includes numerous hoses to provide additional attachments to the product. It contains additional add-on options like IndraControl VAM to enhance the I/O facilities. The drive can be equipped with many different communication cards, such as SERCOS III, EtherCAT and PROFINET, which simultaneously makes the drive compatible with many other control systems. Special solutions include an integrated braking resistor attachment, which is helpful for dynamic braking and improving safety and control. Moreover, the controller has a graphic display for diagnosing and monitoring the ongoing systems or components in operation. These attachments make the HCS011E-W0018-A-03 versatile and performant for various requirements of industrial automation systems.

Standard Safety Precautions:

The Indramat HCS01.1E-W0018-A-03 conform to strict safety requirements such as IEC 61800-5-1 for electrical safety and EN 60204-1 for the safety of machines. For safer operation and to safeguard the unit from overvoltage, overcurrent, and short-circuit conditions, protection circuits are incorporated.

The user should always confirm grounding needs and follow installation procedures to minimize the risks connected with electrical problems. It is also advisable to follow up on the performance and undertake routine checks to reduce failure due to neglect. It should be located within the temperature range of 0°C to +40°C and incorporate an IP20-rated housing to prevent contamination by dust or deliberate and unintentional interaction. All these measures are crucial in ensuring that the devices operate to the expected level of efficiency and safety in industries.

Frequently Asked Questions:

What input voltage does the Indramat HCS01.1E-W0018-A-03 support?

The Indramat HCS01.1E-W0018-A-03 drive controller supports an input voltage of 200-240V AC, suitable for a range of industrial power systems.

What communication interfaces are compatible with this drive controller?

It is compatible with SERCOS III, EtherCAT, and PROFINET communication interfaces, providing flexible connectivity options for various industrial automation applications.

What is the continuous current rating of the HCS01.1E-W0018-A-03?

The HCS01.1E-W0018-A-03 has a continuous current rating of 8 A, ensuring reliable operation under sustained load conditions in industrial environments.
