Indramat HCS02.1E-W0070-A-03-NNNN

The Indramat HCS02.1E-W0070-A-03-NNNN is a servo drive manufactured by Rexroth Indramat Bosch. It belongs to the compact converter HCS series, known for its impressive safety features. These drives combine a power supply and an inverter in the same drive module. The drive has versatile applications in the industry due to reliability and high performance.

Technical Specifications:

The Indramat HCS02.1E-W0070-A-03-NNNN compact converter provides a line power rating of 1.4 to 11 kW with a rated current of 70A. The input voltage range from 200V to 500V AC makes it applicable for a diverse set of industrial applications.

This drive has an in-feeding power supply. The ambient working temperature for the unit is 0 to 40 degrees centigrade. The converter is equipped with an IP20 degree of protection which ensures no degradation in efficiency while working in an industrial environment. Data memory used in the system is non-volatile for smooth performance in the industry.

The drive controller has two important parts with different functions for the users. One is the power section, and the other is the control section. There is a power section, which is well incorporated into the control section. Multiple connections are available. The HCS02.1E-W0070-A-03-NNNN drive has a motor connection, possibly with an additional motor-holding brake. There is a motor temperature control unit. The main voltage connection can also be used for the HCS devices and the supply modules.

This unit is equipped with advanced algorithmic control available for precise dynamic motion control. The onboard diagnostic and failure management systems ensure safe operations and less downtime by rapidly identifying and resolving issues.

The Indramat HCS02.1E-W0070-A-03-NNNN drive controller has a unique and smart design for easy integration into existing systems. It merely weighs 7.05 kg, and its dimensions in cm are 45 x 47.5x 27.

Safety Features:

All the products in HCS02 drives have the latest security measures and products. This will allow operation using a simple open loop or more advanced closed loop function. It includes international compatibility and specific open interfaces.

Overvoltage, under voltage, overcurrent protection, and thermal protection are all measures that are in place to assure the HCS02.1E-W0070-A-03-NNNN is a long-lasting controller. These features ensure stable performance in the harsh industrial environments.

Applications:

The Indramat HCS02.1E-W0070-A-03-NNNN drive controller is ideal for many industries. Mostly, it is used in the printing and paper processing industry due to its high quality and precise results. In the textile industry, drive provides precise control during weaving, spinning, and dyeing.

The Indramat HCS02.1E-W0070-A-03-NNNN is widely used in other industries such as Machine Tool Automation, Packaging Machines, Food and Beverage Processing, Plastic and Rubber Processing, and Assembly and Test Equipment.

Frequently Asked Questions:

What is the maximum current rating for HCS02.1E-W0070-A-03-NNNN?

The HCS02.1E-W0070-A-03-NNNN current rating is 70A, while line power rating ranges from 1.4 to 11 kW

What is the relative humidity of the HCS02.1E-W0070-A-03-NNNN?

The HCS02.1E-W0070-A-03-NNNN has a relative range between 5% and 95%. With this humidity, the drive controller must be free of condensation on its surface.

How long does it take for the live capacitors of the HCS02.1E-W0070-A-03-NNNN to get discharged after the power is turned off?

The live capacitors of the HCS02.1E-W0070-A-03-NNNN take at least half an hour to get discharged after turning off the power supply.
