Mitsubishi GT2715-XTBA

Mitsubishi has the high-performance GT2715-XTBA touch panel in the GT27 series. These panels are designed for advanced human-machine interface (HMI) applications. With its sturdy specifications and features, this model is designed to fulfill the demanding needs of different industrial environments. The model is a flexible solution for control panels due to its design prioritizes dependability, user-friendliness, and numerous connection choices.

Technical Specifications:

The Mitsubishi GT2715-XTBA is characterized by a panel cutout measuring 383.5 x 282.5 mm and external dimensions measuring 397 x 300 x 60 mm. It is small and sturdy, weighing only 4.5 kg. The analog resistive film touch panel allows up to two-point simultaneous pushing and has keys at least 2 × 2 dots in size.

The touch panel's long-lasting design will withstand over one million operations with an operating force of 0.98 N or less. The GT2715-XTBA has many built-in interfaces for connecting to devices. It supports various transmission speeds and comes with D-sub connections for its RS-232 and RS-422/485 channels.

The Ethernet interface's RJ-45 modular jack allows for 10BASE-T and 100BASE-TX. It also has one USB (Device) channel and two USB (Host) channels, which can support data transfers up to 480 Mbps. The interface also supports SDHC cards with capacities of up to 32 GB.

In horizontal installation, the GT2715-XTBA operates from 0 to 55°C; in vertical installation, it operates from 0 to 50°C. -20°C to 60°C are suitable storage temperatures. Without condensation, working humidity is 10%€“90%RH. The gadget is shock-resistant and meets IEC 60068-2-27 vibration resistance criteria for continuous and intermittent vibrations at different frequencies.

Memory Specifications:

The GT2715-XTBA boasts a user memory capacity of 57 MB of ROM for storage and 128 MB of RAM for operation. The device's memory supports up to 100,000 write cycles. At 25°C, its internal clock has an accuracy of ±90 seconds per month. The gadget runs on a GT11-50BAT lithium battery, which should last about five years when kept at room temperature.

Additional Specifications:

The GT2715-XTBA is designed for control panel installation and works at 2000 meters. This is an overvoltage area with two or less pollutants. The cooling system requires a ground cable with a two mm² cross-sectional area and a resistance of 100? or less to operate independently.

It operates on 100€“240 VAC and 50/60 Hz. The maximum load is 51W, while stand-alone usage is 25W and 10W with the lights off. The inrush current shall not exceed 40A at 25 °C and the maximum load.

It withstands millisecond power outages of 100 VAC or greater. The device has 1500Vp-p noise resistance and can withstand 1500VAC between the power source terminal and ground for one minute. A 10M? or higher grade indicates insulating resistance. Terminal screws can secure wire diameters from 0.75 to 2 mm² with a tightening torque of 0.5 to 0.8 N·m.

Frequently Asked Questions:

How much memory does the Mitsubishi GT2715-XTBA have?

The GT2715-XTBA has 128MB of RAM for running programs and 57MB of ROM for storage. This large amount of memory makes it easy to handle and process info.

What number of USB ports does the Mitsubishi GT2715-XTBA offer?

The Mitsubishi GT2715-XTBA has three USB ports: two for hosts and one for devices. These enable data transfers at speeds of up to 480 Mbps.

What temperature range does the Mitsubishi GT2715-XTBA work in?

When installed horizontally, the GT2715-XTBA can withstand temperatures up to 55°C; when installed vertically, it can withstand temperatures down to 50°C. Reliability in a wide range of environmental conditions is guaranteed.
