TECHNICAL SPECIFICATIONS

Schneider Electric 140CPS12420

The Modicon Quantum automation product range has this standalone power supply module 140CPS12420, designed to reduce energy consumption efficiently. With a power rating of 160 VA, this model has an inrush current of ‰¤ 25 A at 230 V and ‰¤ 20A at 115V. Additionally, to ensure effective use, the fuse should be rated for 2 A.

Technical Description of 140CPS12420:

This model 140CPS12420 offers exceptional power with a harmonic distortion of < 10%. Boasting an impressive 5.1V DC voltage and 11A current, this high-performance device is certain to meet any needs.

This model 140CPS12420 can support an impressive range of input voltage between 93 to 138 V AC or 170 to 263 V AC at a frequency that spans 47-63 Hz. Its capacity stands strong, executing 0.7 A at 230 V and 1.2 A with a 115 V power source, respectively.

To ensure robust performance, the 140CPS12420 standalone power supply module features internal output overvoltage and overcurrent protection. A single green LED is present to signify a successful operation.

Quantum's special-purpose computing system offers digital processing capabilities for real-time control in industrial and manufacturing settings. The model has an expandable architecture that makes it versatile and suitable for meeting production needs of any size.

Standard Ambient Conditions:

Ensure the correct and responsible disposal of this product by taking it to designated waste collection sites, never in a trash bin. Complying with the EU RoHS Directive for its mercury-free composition, we designed the model 140CPS12420.

The optimal ambient air temperature for operating the model is between 0 - 60°C, and it can be installed at altitudes up to 5000 meters without any performance degradation.

Maintaining an ambient temperature between -40 and 85 degrees centigrade is critical for optimal model storage, while relative humidity must be below 95 percent for successful operation.
