TECHNICAL SPECIFICATIONS

Schneider Electric 140CRP93100

The Schneider Electric 140CRP93100 is an RIO (Remote Input/Output) head-end adapter module designed for use with the Modicon Quantum programmable logic controller (PLC) system. It features a single connector with a single cable configuration, which allows for a simplified and streamlined connection to remote I/O devices.

Technical Specifications:

As an RIO head-end adapter, the module 140CRP93100 offers smooth communication between the Quantum PLC and remote I/O devices, allowing for the exchange of digital and analog signals, as well as field device control and monitoring.

This allows for the integration of a wide range of sensors, actuators, and other I/O devices into the control system, expanding its capabilities and improving overall automation system functionality.

The installation process is simplified and expedited by using a single connector and cable. Wiring faults and connection problems are reduced, saving time and effort during installation. The streamlined shape also aids in the efficient use of space within control cabinets or equipment enclosures.

Furthermore, the use of a single cable simplifies maintenance work. Because there is just one wire to inspect and manage, troubleshooting and diagnosis become easy. It enables faster discovery and resolution of possible problems, resulting in less downtime and increased system reliability.

It has a power dissipation of 3 Watt (W), a transmission rate of 1544 Mbit/s, and a dynamic range of 35dB. The 140CRP93100 has an ambient air temperature of 32 to 140 °F (0 to 60 °C) for operation and an ambient air temperature of -40 to 185 °F (-40 to 85 °C) for storage.

RoHS and REACh Compliance:

The RoHS (Restriction of Hazardous Substances) and REACh (Registration, Evaluation, Authorization, and Restriction of Chemicals) rules are both met by the Schneider Electric 140CRP93100 module.

The module is RoHS compliant, which limits the use of hazardous compounds in electrical and electronic devices. This assures that the module is free of these dangerous compounds, improving environmental sustainability and reducing potential human health hazards.

The module also meets the requirements of the REACh regulation, which aims to ensure the safe use and handling of chemicals throughout their life cycle. Chemicals used in diverse industries must be registered, evaluated, and authorized under REACh.

The 140CRP93100 module complies with REACh requirements by employing registered or authorized compounds and adheres to the REACh notification responsibilities regarding the presence of substances of very high concern (SVHC).

The Schneider Electric 140CRP93100 module proves its commitment to environmental sustainability and the responsible use of chemicals by complying with both RoHS and REACh requirements. It ensures that the module has been subjected to the essential assessments and controls in order to meet the stringent criteria of these standards.

Network Support:

The module has Ethernet connectivity, making it simple to integrate into Ethernet-based networks. It is compatible with TCP/IP (Transmission Control Protocol/Internet Protocol), UDP (User Datagram Protocol), and ICMP (Internet Control Message Protocol) common Ethernet protocols. This enables the module and other networked devices to send data in a reliable and efficient manner.

Aside from Ethernet, the module supports other industrial communication protocols, including Modbus TCP/IP, Modbus RTU, and Modbus ASCII. These protocols are frequently used in industrial automation applications and allow devices from many manufacturers to communicate with one another.

The 140CRP93100 module's extensive network functionality enables simple integration into existing network infrastructures. It provides real-time data interchange, remote monitoring, and control, improving the automation system's overall efficiency and performance.
