TECHNICAL SPECIFICATIONS

Schneider Electric 140NOC78000

This Schneider Electric's Ethernet I/O head module 140NOC78000 is an innovative and versatile tool for various applications. Featuring exchange mode capabilities with up to 128 connections, it brings efficient performance to any environment.

Technical Specification of 140NOC78000:

Boasting Modbus TCP and EtherNet/IP communication ports, this 140NOC78000 model's transmission rate is 10/100 Mbit/s with a hot standby redundant architecture. Also embedded in its design is the web server feature ensuring reliable operation.

The 140NOC78000 module facilitates efficient communication between I/O and PLC devices on different networks. It ensures seamless operations coordination with no additional latency, delivering superior performance for distributed applications.

This Ethernet I/O head module has a lightweight build of 0.345 kg and is equipped with an RJ45: 10BASE-T/100BASE-TX ethernet port, providing transmission support via the twisted pair medium. It also offers reliable protection thanks to its IP20 class rating.

The 140NOC78000 model features 6 LEDs that serve various purposes. A bright green LED signals the active bus communication, while another indicates the configuration status. Additionally, a dual-color (green/red) LED illuminates when the module and network statuses are in effect.

This Ethernet I/O head module model is powered by the rack power supply and CE compliant, with RSTP Ethernet service for rapid scanning operations.

Interface capabilities are provided to the Quantum EIO system through a module installed on its local rack, giving users control over distributed I/O devices and client applications within an Ethernet remote I/O network. For the best results, use the model 140NOC78000 within the temperature range of 0 to +60°C and keep the operational relative humidity below 95%.
