Schneider Electric ATV312HD15N4

Schneider Electric Atv312Hd15N4

Schneider Electric ATV312HD15N4

A high-performance variable-speed drive, the Schneider Electric ATV312HD15N4 is a member of the esteemed Altivar 312 series. It is intended for industrial applications and provides precise control and efficacy for asynchronous motors. This drive is designed to operate efficiently and reliably in a variety of environments, thanks to its sophisticated features and robust protection mechanisms.

Technical Specifications:

With 380-500 V supply voltage, the ATV312HD15N4 works in many power systems. It supports 50-60 Hz supply frequencies, making it industrially applicable. It operates in three-phase systems, making it industrial-friendly.

ATV312HD15N4's 15 kW motor powers demanding work. It handles heavy loads with 48.2 A at 380 V and 36.8 A at 500 V line current. Devices have EMC filters for electromagnetic compatibility.

The 32 kVA apparent power of the ATV312HD15N4 illustrates its efficiency and power handling. It can handle a maximum transient current of 49.5 A for 60 seconds, displaying a quick load variation response. Nominal load power dissipation is 492 W, exhibiting energy efficiency.

The ATV312HD15N4 motor control is flexible at 1-50 mph. Controlling motors with PWM and sensorless vectors improves their efficiency and performance. The factory-arranged drive's consistent torque makes it suitable for various industrial applications.

Three voltage and current-configurable analog inputs, AI1, AI2, and AI3, enhance the drive's versatility. AI1 can handle 0-10 V signals, AI2 ±10 V signals, and AI3 0-20 mA signals, making it versatile for various control needs.

Environmental Specifications:

With a cover, the ATV312HD15N4 works well at -10°C to +50°C and +60°C when derating. It can withstand shipping and storage at -25°C to +70°C. The drive works well at 5-95% non-condensing humidity.

A 1% current derating ratio every 100 m allows this variable speed drive to operate at 1000 m without derating and 3000 m with derating. In severe environments, 11 ms shock resistance and 13-150 Hz vibration resistance assure stability and longevity.

The drive's protection rating depends on installation: IP20 for the top without a cover plate, IP21 for the connecting terminals, IP31 for the upper area, and IP41 for the upper portion, giving versatility. These grades dust and water-proof the drive and improve reliability.

Communication and Connectivity:

The ATV312HD15N4 supports Modbus and CANopen for versatile connectivity. This allows smooth connection into automation systems for remote monitoring and control. An RJ45 Modbus/CANopen connector allows an RS485 multidrop serial link, expanding the drive's connectivity.

To improve communication, the ATV312HD15N4 supports CANopen daisy chain, DeviceNet, Fipio, Modbus TCP, and Profibus DP option devices. This versatility ensures that the drive can meet a variety of communication needs, making it suitable for usage in many industrial contexts.

Frequently Asked Questions:

The Schneider Electric ATV312HD15N4 has what voltage range and power rating?

The ATV312HD15N4 from Schneider Electric can run on voltages ranging from 380 to 500V and boasts a 20 HP motor power rating.

In what manner does the ATV312HD15N4 regulate transient currents and power dissipation?

The ATV312HD15N4 has a nominal load power dissipation of 492 W and can manage a maximum transient current of 49.5 A for 60 seconds. During peak demand conditions, these attributes optimize its energy efficiency and performance.

What are the ATV312HD15N4's operating temperature and altitude specifications?

It is capable of being installed at altitudes of up to 1000 m without derating and operates within a temperature range of -10 to +50°C when equipped with a protective cover. The drive's dependability in a variety of environmental conditions is guaranteed by these specifications.

Product Specifications Table:

Attributes Specification
Product Type Variable Speed Drive
Product Range Altivar 312
Motor Power 15 kW (20 HP)
Rated Supply Voltage 380-500 V
Supply Frequency 50-60 Hz
Line Current 48.2 A at 380 V, 36.8 A at 500 V
Apparent Power 32 kVA
Maximum Transient Current 49.5 A for 60 seconds
Power Dissipation 492 W at nominal load
Communication Protocols Modbus, CANopen
