TECHNICAL SPECIFICATIONS

Schneider Electric ATV320U40N4B

The groundbreaking Schneider Electric ATV320U40N4B is an innovative motor drive created to provide top-notch performance and versatility for an arrangement of industrial uses. Featuring a compact design and a comprehensive range of features, this advanced motor drive is the ideal solution for all manufacturing needs.

Technical Guidelines:

The ATV320U40N4B drive is a compact and efficient solution for manufacturing needs. With its book format design, it's easy to integrate into control cabinets for a secure installation, saving valuable space. And it's perfect for various industrial conditions.

The model is designed with multiple communication port protocols, like Modbus serial and CANopen, to ensure smooth connectivity and compatibility with other industrial devices and systems.

This powerhouse drive supports optional communication modules like EtherCAT, PROFINET, and EtherNet/IP, to offer versatile networking capabilities. With its advanced features, this drive offers seamless communication options that are easy and convenient to use.

The ATV320U40N4B packs a heavy-duty punch with its 9.5 A output current (nominal) and 4.0 kW motor power. Designed to operate within a range of 380 - 500 V, this drive offers reliable and efficient control for manufacturing motors. This powerful drive can help do the job with ease and precision.

The drive technology stays protected from dust and interference. It comes equipped with a Class C2 EMC filter for effective electromagnetic compatibility and reduces interference with other equipment. And enjoy peace of mind with its high-level safety rating of IP20.

The versatile drive with multiple input and output options to suit all control needs! With 7 input options, it can easily add STO, logic, and programmable pulse inputs. And, the drive supports 3 output options, including open collector DQ+ and DQ- configurations.

The powerhouse drive has 3 analog inputs and 1 analog output for precise voltage, current, and parameter monitoring and control. This drive is best for seamless operations.

The adaptable ATV320U40N4B offers reliable switching capabilities, which boast configurable relay logic. This drive comes with multiple relay outputs that support various load types and voltages, making it a seamlessly integrative addition to industrial control techniques.

The ATV320U40N4B has a compact drive that's only 60 mm wide and weighs just 3.0 kg. Perfect for control cabinets where space is at a premium, this efficient drive can operate in temperatures ranging from -10°C to 50°C (with derating up to 60°C). And it meets all environmental standards for temperature, humidity, vibration, and shock, so it can rely on it to perform no matter the conditions.

This mighty device meets a range of international standards and certifications - CE, ATEX, NOM, GOST, EAC, RCM, and KC - giving the peace of mind that it'll perform well under pressure. And it's built to resist electrical disturbances, due to its electromagnetic compatibility (EMC) compliance.

Control the motors with ease using this ATV320U40N4B drive. This versatile device offers control profiles for asynchronous and synchronous motors, as well as advanced features such as voltage/frequency ratio control and flux vector control without a sensor. With precise motor control and energy-saving capabilities, the drive is the perfect choice for optimizing operations.

Safety Precautions:

Stay Safe While Maintaining the drive ATV320U40N4B. Disconnect from Power and Follow Lockout/Tagout Procedures. Prioritize safety by taking necessary steps to avoid electric shocks and other hazards. And be sure to properly ground the equipment according to the instruction manual to prevent electrical faults and ensure safety.
