TECHNICAL SPECIFICATIONS

Siemens 1FT6105-1AC71-1AG1

The Siemens 1FT6105-1AC71-1AG1 model is an advanced, meticulously crafted synchronous motor of the SIMOTICS S Series that comes from the prestigious house of Siemens. The SIMOTICS S Series is recognized for its high dynamic and precision.

Technical Specifications:

The 1FT6105-1AC71-1AG1 motor features a compact, self-cooled design with natural convection. The motor is encased within a robust body, making it resistant to external physical impacts. Despite its advanced functions, it is lightweight for its class, ensuring easy handling and installation.

The efficient motor showcases a high dynamic response, ensuring precision control in high-speed applications. This feature makes it suitable for tasks that demand fast and precise responses, such as robotics, printing, and packaging.

The motor operates at a maximum speed range of up to 5600 RPM, delivering consistent performance across a variety of applications. It also produces a high standstill torque, ensuring a reliable start and smooth operation.

The Siemens 1FT6105-1AC71-1AG1 operates at a rated voltage of 600 V. The motor demonstrates a high power density of 7.96 kW, which, coupled with its low energy consumption of 103 A, makes it a cost-effective and sustainable choice for industrial applications.

The motor is equipped with an absolute encoder with 2048 S/R (signals per revolution). This feature provides enhanced control and precision in positioning tasks.

This motor supports IM B5 (flange) mounting according to DIN EN 50347. This standardized mounting option ensures compatibility with a wide range of equipment and eases the installation process. The motor incorporates high-performance bearings designed to endure high radial and axial loads. The use of these bearings enhances the lifespan of the motor and reduces maintenance needs.

Environmental Specifications:

The 1FT6105-1AC71-1AG1 motor can operate efficiently under a wide range of ambient temperatures. This feature ensures its high performance and longevity, even in challenging environmental conditions. The motor comes with a protection rating of IP65, ensuring it is dust-tight and protected against water jets. This high degree of protection allows for its use in a variety of industrial settings.

The Siemens 1FT6105-1AC71-1AG1 motor employs a self-cooling mechanism. This feature enhances its performance by preventing overheating, even during prolonged and intensive operations. The motor boasts of an insulation class F according to IEC 60034-1. This higher insulation class safeguards the motor from high temperature and voltage stresses, thus enhancing its reliability and durability.

This high-performance motor adheres to CE regulations, confirming its safety standards. Additionally, it is compliant with UL and CSA certifications, which further reinforces its safety and reliability.

Compatibility and Recommended Use:

The motor 1FT6105-1AC71-1AG1 offers flexibility with its connectivity options. The motor is designed to integrate seamlessly with Siemens' range of drives and automation systems. The motor complies with international standards like EN 60034 and IEC 60034, ensuring safety, reliability, and quality.

The model maintains a low noise emission level during operation. This attribute, coupled with its vibration-free operation, makes it an ideal choice for noise-sensitive applications. The motor has a long service life, owing to its sturdy construction and use of high-quality components. This ensures minimal maintenance costs and downtime, resulting in increased productivity.

The 1FT6105-1AC71-1AG1 motor is designed for continuous operation (S1 at 100 K/40 °C). This means it can operate continuously without the need for intervals between operations, making it ideal for continuous production lines and demanding industrial applications.
