TECHNICAL SPECIFICATIONS

Siemens 6AV2124-0QC02-0AX1

The Siemens 6AV2124-0QC02-0AX1 is a SIMATIC HMI TP1500 Comfort panel. This HMI panel features a 15 widescreen TFT display with touch operation, allowing users to interact with industrial automation systems and control processes. The display supports 16 million colors, providing a high-quality visual experience for process visualization.

General Specifications of the Product:

The 6AV2124-0QC02-0AX1 includes a PROFINET interface, allowing for smooth integration into industrial networks. It also offers an MPI/PROFIBUS DP interface for connecting various automation devices. These interfaces ensure that the HMI panel and other automation components communicate effectively.

It has 24 MB of configuration memory, providing enough storage space for project data and settings. This enables the HMI panel to be configured in a flexible and efficient manner to satisfy unique application needs.

The WEC 2013 (Windows Embedded Compact 2013) operating system is supported by the HMI panel. It can be set using HSP (Human System Partner), a software tool for creating and programming HMI applications, using WinCC Comfort V14 SP1. This software compatibility improves the TP1500 Comfort panel's usage and versatility.

The TP1500 Comfort panel is intended to work in temperatures as high as 50 °C. It should be noted, however, that if the temperature exceeds 50 °C, its functionality may be restricted or limited. Adhering to the recommended temperature range maintains the panel's optimal performance and lifespan.

Control Elements of the Panel:

The SIMATIC HMI TP1500 Comfort panel includes various control features to improve user engagement and control. The touchscreen interface is one of the key control elements. The panel has a high-quality touchscreen display that allows users to interact with the displayed content directly.

Operators can traverse menus, pick options, and interact with graphical elements on the screen by employing touch gestures like as tapping, swiping, and pinching. The touchscreen provides a simple and easy-to-use control interface.

The 6AV2124-0QC02-0AX1 often has customizable function keys in addition to the touchscreen. Based on the application needs, these physical keys can be customized and assigned unique functions.

Function keys allow operators to quickly access frequently used commands or actions, allowing them to complete jobs more efficiently. Because the function keys may be programmed, they can be customized and adapted to specific procedures or workflows.

The TP1500 Comfort panel frequently includes dedicated navigation buttons to assist easy navigation and screen changeover. These buttons often feature up, down, left, and right arrows, which allow operators to traverse menus, scroll through lists, and switch between screens or pages.

The navigation buttons are a helpful alternative to touchscreen engagement, particularly in situations requiring precise control or fast motions.

Interfaces of the Panel:

The 6AV2124-0QC02-0AX1 is equipped with various interfaces that facilitate seamless communication and integration with other components of an industrial automation system. These interfaces enable the panel to connect to different devices and networks.

The panel includes a PROFINET interface, a popular industrial communication standard. PROFINET enables high-speed data interchange between the HMI panel and other PROFINET-compatible network devices. This interface allows for real-time control and monitoring of automation operations, as well as efficient and dependable communication.

It also comes with an MPI/PROFIBUS DP interface. MPI (Multi-Point Interface) and PROFIBUS DP (Decentralized Peripherals) are well-known industrial automation fieldbus protocols.

The MPI/PROFIBUS DP interface allows the panel to communicate with devices that accept these protocols, such as PLCs and other field equipment. This interface allows the HMI panel and the linked devices to exchange data, control signals, and parameter settings.
