TECHNICAL SPECIFICATIONS

Siemens 6AV6643-0BA01-1AX0

The Siemens 6AV6643-0BA01-1AX0 model is a model from the established SIMATIC HMI TP177B series. This Human Machine Interface (HMI) provides a powerful and reliable solution for various automation requirements. Its robust design combined with advanced features makes it an optimal choice for industrial applications.

Technical Specifications:

The 5.7 STN display of model 6AV6643-0BA01-1AX0 not only offers rich color presentation but also ensures exceptional readability under various lighting conditions. The resistive analog touch screen further facilitates responsive and precise input, making user interaction easy and effective.

The model offers a resolution of 320 x 240 pixels, ensuring clear visual feedback. The display supports 256 colors, providing rich and vibrant visuals that enhance the operator's experience. The model includes a resistive analog touch screen, allowing easy and interactive operation.

The device is equipped with a high-performance processor for fast and efficient operation. With 4 MB of memory, this HMI model accommodates extensive data storage and management, including project data, logs, and essential system backups. Such ample memory space enables operators to maintain intricate control over their applications.

The model features an MPI/DP interface, supporting reliable and efficient data communication. The 6AV6643-0BA01-1AX0 boasts a robust design that is dust and waterproof, making it suitable for harsh industrial environments.

The device has compact dimensions (308 mm x 204 mm x 59 mm), facilitating its installation in various setups. The device has a weight of approximately 1.19 kg, contributing to its portability and ease of installation.

The model 6AV6643-0BA01-1AX0 is readily compatible with the WinCC flexible 2008 SP1 or later. This compatibility allows operators to customize their HMI using a well-recognized software suite, ensuring a user-friendly configuration experience. This HMI device operates with a 24 V DC power supply, commonly available in industrial settings.

The device supports multiple languages, enhancing its usability across different geographical locations. It includes an integrated alarm system that alerts operators to critical events in real-time. The device provides options for configuration backup, ensuring that important setups can be easily restored in case of system failure.

The HMI includes integrated security measures, allowing for user-specific access control. The energy-saving mode reduces power consumption during periods of inactivity, contributing to energy-efficient operation.

The model 6AV6643-0BA01-1AX0's design, aimed at industrial applications, provides superior resistance to dust and water. This rugged construction ensures the HMI can withstand the harsh conditions often present in industrial environments, leading to prolonged device longevity.

General Safety Precautions:

The model 6AV6643-0BA01-1AX0 is a versatile and advanced device that requires careful consideration of safety precautions to ensure the well-being of users and efficient operation. When operating this HMI model, it is crucial to prioritize safety measures to prevent accidents and maintain a secure working environment.

Understanding the device's capabilities and limitations is vital for safe operation. Additionally, it is crucial to regularly update the firmware and software of the HMI to ensure optimal performance and security.

When installing the 6AV6643-0BA01-1AX0 HMI, proper grounding techniques and electrical safety protocols must be followed to prevent electrical hazards. Utilizing appropriate protective equipment, such as gloves and safety glasses, can minimize the risk of physical injury while working with the HMI.

Furthermore, users should ensure that the HMI is installed in an environment that meets the specified temperature, humidity, and vibration requirements.

To avoid unintended system errors or unauthorized access, it is essential to implement robust cybersecurity measures. This includes regularly changing passwords, utilizing secure network connections, and implementing firewall protection.
