Siemens 6SL3210-1PB13-0UL0
Siemens 6SL3210-1PB13-0UL0
The Siemens 6SL3210-1PB13-0UL0 power module is designed for efficient power management. It operates with a line voltage range of 200 to 240V ±10%. The line frequency supported is 47 to 63 Hz. The power module is compatible with single and three-phase AC inputs. For rated current, it provides 7.50 A / 4.30 A for low overload and 6.60 A / 3.80 A for high overload. The module outputs three-phase AC with a rated voltage of 230V according to IEC and 240V per NEC standards.
Power Ratings:
For power ratings, the module offers 0.55 kW for low overload and 0.37 kW for high overload. It provides a rated current of 3.20A for low overload and 2.30A for high overload. The maximum output current of the module is 4.80A. The pulse frequency is set at 4 kHz. The output frequency ranges from 0 to 200 Hz for vector control and 0 to 550 Hz for V/f control.
The Siemens 6SL3210-1PB13-0UL0 module has significant overload capabilities. For low overload, it can handle 110% of the rated current for 57 seconds and 150% for 3 seconds, both within a cycle time of 300 seconds. For high overload, it manages 150% of the output current for 57 seconds and 200% for 3 seconds, also within a 300-second cycle.
Technical Specifications:
The power factor of the module is 0.85, and the offset factor is cos ? 0.95. It boasts an efficiency rating of 0.96 and a sound pressure level of 50 dB at a distance of 1 meter. The power loss is minimal at 0.04 kW. The module includes an integrated filter for added performance.
Cooling for the 6SL3210-1PB13-0UL0 is provided by internal air cooling, requiring an air volume of 0.005 m³/s. It can be installed at altitudes up to 1,000 meters. The operating temperature ranges are -5 to 40°C for low overload and -5 to 50°C for high overload. For transport and storage, the temperature range is -25 to 55°C. The module can operate in environments with up to 95% relative humidity, provided there is no condensation.
Connections and Compliance:
Connection to the power module is facilitated through plug-in screw terminals. The conductor cross-section ranges from 1.00 to 2.50 mm². The maximum motor cable length is 50 meters for shielded cables and 100 meters for unshielded cables.
The mechanical design of the 6SL3210-1PB13-0UL0 power module adheres to IP20 / UL open type protection standards. The frame size is FSA with a net weight of 1.40 kg. The dimensions are 73 mm in width, 196 mm in height, and 165 mm in depth. This power module complies with several standards including UL, cUL, CE, C-Tick (RCM), and SEMI F47. It also meets the low-voltage directive 2006/95/EC and is classified under efficiency class IE2 according to IEC61800-9-2 standards.
Frequently Asked Questions:
What is the operating temperature range for the Siemens 6SL3210-1PB13-0UL0?
The Siemens 6SL3210-1PB13-0UL0 operates within -5 to 40°C for low overload and -5 to 50°C for high overload. It can be stored or transported in temperatures ranging from -25 to 55°C, ensuring reliability in various environments.
What are the overload capabilities of the Siemens 6SL3210-1PB13-0UL0?
For low overload, the module handles 110% of the rated current for 57 seconds and 150% for 3 seconds within a 300-second cycle. For high overload, it manages 150% of the rated current for 57 seconds and 200% for 3 seconds within the same cycle.
How does the Siemens 6SL3210-1PB13-0UL0 manage cooling?
The module uses internal air cooling, requiring an air volume of 0.005 m³/s. This efficient cooling system allows the power module to operate effectively at altitudes up to 1,000 meters and in environments with up to 95% relative humidity without condensation.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Line Voltage Range | 200 to 240V ±10% |
| Rated Current (Low Overload) | 7.50 A / 4.30 A |
| Rated Current (High Overload) | 6.60 A / 3.80 A |
| Power Ratings (Low Overload) | 0.55 kW |
| Power Ratings (High Overload) | 0.37 kW |
| Output Frequency (Vector Control) | 0 to 200 Hz |
| Output Frequency (V/f Control) | 0 to 550 Hz |
| Power Factor | 0.85 |
| Efficiency | 0.96 |
| Operating Temperature Range | -5 to 40°C (Low Overload), -5 to 50°C (High Overload) |
