TECHNICAL SPECIFICATIONS

Siemens 6SN1123-1AA01-0FA0

The Siemens 6SN1123-1AA01-0FA0 model represents the most advanced design in Siemens' long-standing series of Simodrive drive systems. This model is manufactured for high-performance industrial applications where reliable motor control is crucial.

Technical Specifications:

The 6SN1123-1AA01-0FA0 model offers a nominal current of 85 A for the operation of induction motors. In normal working conditions, the power module can deliver a peak current of 127 A for the operation of the induction motors and 140 for the operation of the synchronous motors.

It operates on an internal (integral) cooling mode, making the entire system more efficient by ensuring heat generated during operation is effectively dissipated. This module supports various types of motor control methods including V/f control, vector control, and servo control, ensuring a wide range of compatibility with different motor types.

The 6SN1123-1AA01-0FA0 power module comes with an IP00 protection class rating, meaning that the unit itself does not provide extra protection against foreign objects or water ingress. This gives users the flexibility to customize the unit's enclosure to their specific needs.

This Siemens model boasts a rapid dynamic response thanks to its sophisticated control algorithms. This enhances the overall performance by reducing the time taken for the motor to reach the desired speed or torque.

The 6SN1123-1AA01-0FA0 features a modular design that ensures greater reliability and easier maintenance. Parts can be replaced individually, reducing the overall downtime and ensuring longer operational life.

It allows for seamless integration with Siemens' master drive systems and offers SimoCom U communication for efficient data exchange. The Siemens 6SN1123-1AA01-0FA0 power module is built to handle the rigorous demands of industrial settings, constructed with high-quality materials ensuring durability and long-term reliability.

This module uses a rack-mounted design, ensuring space-efficient installation within a cabinet or enclosure. This approach helps conserve precious floor space in tight industrial environments. The power module has a compact size and a low weight of 26 kilograms, facilitating convenient and space-saving installation.

The module accepts encoder feedback to achieve precise speed and position control. This allows for improved performance and higher accuracy in motion-controlled applications. The unit functions at a frequency of 50/60 Hz, ensuring global compatibility and functionality.

The model 6SN1123-1AA01-0FA0 operates at an input voltage of 600 V DC. This range of voltage compatibility ensures that the module can adapt to the power infrastructure in various geographical locations.

Safety Measures:

The 6SN1123-1AA01-0FA0 offers excellent protection against overload with its integrated protection features, safeguarding both the module and the connected motors. The unit is also designed with safety in mind, providing safety-integrated functions to minimize the risk of injury to personnel and damage to machinery.

The module incorporates clear alarm and fault indicators for rapid problem identification and resolution, reducing the potential for significant operational downtime. The power module ensures electrical isolation between power and control circuits, reducing the risk of electrical shocks or short circuits. The module is designed to be short-circuit-proof, providing an additional layer of safety for users and connected motors.

Additional Features:

The 6SN1123-1AA01-0FA0 power module includes integrated noise suppression measures to mitigate electromagnetic interference, ensuring stable and reliable operation. It comes equipped with a DRIVE-CLiQ interface for connection with other Siemens components. This feature facilitates seamless integration and easier troubleshooting. The module incorporates LED diagnostics for real-time fault detection and rectification, further improving the system's uptime.
