Siemens 6SN1145-1BA01-0BA2

Siemens 6Sn1145-1Ba01-0Ba2
Siemens 840D Test Stand

Siemens 6SN1145-1BA01-0BA2

Regular price
$2,512.00
Sale price
$2,512.00
We currently have 2 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Description

SIMODRIVE 611 INFEED/REGENERATIVE FEEDBACK MODULE 16/21 KW, STABILIZED, WITH INTERNAL COOLING, MAINS CONTACTOR WITH BREAK CONTACT


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 6SN1145-1BA01-0BA2-R $2,512.00 USD 2 Year Extended Warranty 2 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Siemens 6SN1145-1BA01-0BA2

The Siemens’ 6SN1145-1BA01-0BA2 model sets the industry standard for feedback module reliability and performance. The Infeed Module is designed to provide regulated electrical output for various components within an industrial automation system. It converts the incoming power supply into a stable and controlled output voltage suitable for driving motors, feedback, and control units.

Siemens 6SN1145-1BA01-0BA2

The 6SN1145-1BA01-0BA2 infeed module is perfectly complemented for operation with Siemens SIMOFEEDBACK 611 regenerative systems. The unit is highly adaptable and can be utilized among various industrial applications, and supports a vast range of motors and feedback units.

The specific input voltage range, input frequency, and input current requirements depend on the connected power supply unit. The module ensures the safe and efficient operation of connected devices by offering protection features such as overload protection, short circuit protection, and overvoltage protection. It may also include temperature monitoring to prevent overheating.

The 6SN1145-1BA01-0BA2 module's output voltage, output current, and output power vary based on the specific configuration and application requirements. To guard against voltage spikes or surges, the infeed module may also integrate overvoltage protection, monitoring the output voltage and intervening if it exceeds the specified limit.

Temperature monitoring is another critical feature, enabling the module to oversee internal temperatures and take appropriate actions to prevent overheating. If the temperature rises above recommended levels, the module can adjust its operation or trigger an alarm to ensure safe operation.

Compact and robust, this module, with its aluminum housing, offers a power range of 16 to 21 KW. It also includes an integrated cooling fan that effectively dissipates heat during operation while maintaining optimal temperature control. With its reliability, high-level features, and compact design, the module is the perfect addition to modern automation systems.

Ambient Operating Parameters:

The infeed module 6SN1145-1BA01-0BA2 can only function properly and last as long as intended under certain environmental conditions. Temperatures exceeding 55 degrees Celsius necessitate derating. However, the maximum operating is 50 degrees Celsius. Store the feedback module between -25 degrees Celsius and 70 degrees Celsius to maintain functionality.

Humidity must be kept below 95% without condensation to keep working properly. Keep the module in a clean environment, free of corrosive vapors, dust, and other potential performance-killing pollutants. Furthermore, installation in a vibration-free and shock-free environment will prevent operational issues.

Grounding and Transportation:

Proper installation grounding procedures are necessary for electrical safety and long-term operational success. Local regulations and guidelines should be consulted to ensure the module is properly grounded, utilizing applicable grounding cables and connectors. Not only will this serve to minimize electrical noise, but it will also protect against electrostatic discharge.

Protect the 6SN1145-1BA01-0BA2 infeed module from any physical damage during transportation. The module should be securely packaged and shielded from potential shock, vibration, and extreme temperatures. Utilizing original packaging or specialized transportation containers will help maintain its integrity.

Safety Recommendations:

Before conducting maintenance or servicing activities, disengage the power supply to fully de-energize 6SN1145-1BA01-0BA2. Only qualified personnel with the necessary expertise must install, configure, and troubleshoot the module employing all applicable safety standards and guidelines outlined by Siemens and local regulatory authorities. Examine the module regularly for signs of damage or wear - should any issues be identified, contact Siemens customer support.

To prevent the module from overheating, make sure it is situated in a well-ventilated area. Stay away from installing the system near any heat sources, corrosive substances, or environments with excessive dust or moisture.

Verify that the available power source meets the system's requirements. Protect the system from electrical faults using appropriately-rated fuses or circuit breakers.
