TECHNICAL SPECIFICATIONS

Siemens 6SN1145-1BA02-0CA1

The Siemens 6SN1145-1BA02-0CA1 model is a remarkable device known as a SIMODRIVE 611 Universal Infeed/Regenerative Feedback Unit, devised to supply power to the drive controllers. It's a quintessential part of the industry-leading SIMODRIVE series, designed to provide top-notch control and drive solutions for industrial applications.

Technical Specifications:

The model 6SN1145-1BA02-0CA1 operates with an output voltage of 600 or 625 V at 50/60Hz, providing ample flexibility for use in various industrial settings. The unit offers an output voltage that matches the input voltage, effectively powering up drive controllers.

The model weighs 10.5 kilograms and has a rated current of 67 A. The unit possesses a 47 kW power rating. This capacity is ideal for handling high-demand applications, ensuring consistent, reliable performance even in taxing environments.

Featuring a forced ventilation cooling mode, the unit 6SN1145-1BA02-0CA1 ensures maximum heat dissipation. This feature enhances durability and longevity, protecting the unit from overheating during prolonged operational hours.

One of the core features of the model is its regenerative feedback functionality. This feature allows the unit to feed back energy into the supply system, increasing overall efficiency, and making it an environmentally friendly solution.

The unit showcases high overload capacity, ensuring continuous operation even under demanding conditions. This makes it a reliable and robust option for applications that require sustained high performance.

Despite its powerful performance, the 6SN1145-1BA02-0CA1 maintains a compact design, facilitating easier integration into control cabinets and allowing for optimum space utilization. The module ensures optimal functionality for a wide array of applications. The device's versatility makes it suitable for multiple industries, from manufacturing and automation to robotics and beyond.

Safety is paramount in the model's design. The 6SN1145-1BA02-0CA1 complies with international standards and regulations, ensuring a high level of operational safety. It also features numerous in-built safety measures to prevent any unwanted incidents.

The robust construction of the model enhances its lifespan and reliability. It's built with high-quality materials that can withstand tough industrial conditions, offering an impressive service life.

Advanced Controls and Diagnostics:

The model 6SN1145-1BA02-0CA1 integrates an advanced microprocessor that enhances its control capabilities. This not only ensures better performance but also allows for precise adjustments, optimizing energy consumption.

The unit features built-in diagnostic capabilities that facilitate trouble-free maintenance and prevent unexpected downtime. The system can detect potential issues early on, allowing for proactive maintenance and ensuring smoother operation.

The regenerative functionality of the 6SN1145-1BA02-0CA1 isn't just environmentally friendly; it also contributes to energy savings. Feeding energy back into the supply system, it minimizes wastage, thereby reducing operational costs.

This Siemens model offers redundancy in power supply, ensuring the continuity of operations even if one part fails. This redundancy feature enhances reliability and prevents potential losses due to unexpected shutdowns.

Compatibility & Integration:

The model 6SN1145-1BA02-0CA1 is designed for compatibility with a wide range of drive controllers. Its flexible design supports different configurations, allowing for seamless integration with existing systems.

Its user-friendly interface simplifies integration into a variety of automation environments. It can be effortlessly connected to other Siemens devices, contributing to a more streamlined and efficient workflow.

Constructed with an innovative modular design, the model 6SN1145-1BA02-0CA1 stands out due to the ease with which its individual components can be maintained or replaced. Its modular structure is specifically designed to allow technicians to quickly isolate and rectify issues without dismantling the entire system.
