Schneider Electric TSXP572634M
Schneider Electric TSXP572634M
The Schneider Electric TSXP572634M is a Unity processor designed for high-performance industrial automation. It is a key component of the Modicon Premium Automation platform that stands out with its Transparent Ready concept. It supports various slot configurations, accommodating extensive I/O needs.
The processor features a substantial discrete and analog I/O capacity. The Unity module has fast, reliable communication with 24 application-specific channels and Ethernet 10BASE-T/100BASE-TX support. Its efficient current consumption and lightweight design enhance its practicality.
Technical Specifications:
The Schneider Electric TSXP572634M is a Unity processor that works on the Transparent Ready concept developed by Schneider Electric. It allows for better system management and control. The product supports a substantial number of racks and slots.
It allows up to 16 racks with 4, 6, or 8 slots. It supports eight racks with 12 slots each. Depending on its utility, the processor provides 128, 96, and 64 slots. The processor capacity for discrete I/O is 1024, and the capacity for analog I/O is 80.
The TSXP572634M offers 24 application-specific channels, adding to its versatility. It ensures the processor can handle diverse applications. It includes an Ethernet port with 10BASE-T/100BASE-TX support. The current consumption is 1650 mA at 5 V DC, optimized for efficiency. The net weight of the Unity processor is 0.042 kg. The lightweight design adds to its practicality.
Execution Time Per Instruction:
The execution time per instruction for the Schneider Electric TSXP572634M Unity processor varies based on the type of instruction and the presence of a PCMCIA card. For Boolean instructions without a PCMCIA card, the execution time is 0.19 µs.
Fixed-point arithmetic or Word instructions without a PCMCIA card take 0.25 µs. Floating-point instructions, whether with or without a PCMCIA card, have an execution time ranging from 1.75 to 2.6 µs.
The Unity processor has different speeds for different tasks. Boolean instructions with a PCMCIA card take 0.21 µs. Fixed-point arithmetic or Word instructions with a PCMCIA card have an execution time of 0.42 µs. These short times show how quickly the processor can handle different tasks.
Operating Environment:
The Schneider Electric TSXP572634M Unity processor is built to perform efficiently in various environments. It operates within an ambient air temperature range of 0 to 60 °C and can be stored in temperatures from -25 to 70 °C. The Unity processor operates at altitudes up to 2000 meters.
The processor functions effectively in relative humidity levels from 10% to 95% without condensation and can be stored in humidity levels from 5% to 95%. The protective treatment is classified as TC and has an IP20 degree of protection. The pollution degree of 2 ensures that the processor can handle occasional condensation.
Frequently Asked Questions:
What is the application structure of the Schneider Electric TSXP572634M Unity processor?
The Schneider Electric TSXP572634M Unity processor supports 64 event tasks, one fast task, and one master task. This configuration allows for efficient handling of various control and automation processes.
What is the system overhead for tasks in the Schneider Electric TSXP572634M?
The system overhead for the Schneider Electric TSXP572634M Unity processor is 0.3 ms for the fast task and 1 ms for the master task. These overhead values indicate the time taken by the system to manage these tasks, affecting overall performance and response time.
Does the Schneider Electric TSXP572634M Unity processor have any certifications?
The Schneider Electric TSXP572634M Unity processor is marked with the CE certification, showing that the product meets the essential safety and protection standards for products supplied in the European Economic Area.
Product Specifications Table
| Attribute | Specification |
|---|---|
| Number of Racks | 16- 4/6/8 slots, 8- 12 slots |
| Number of Slots | 128/96/64 |
| Discrete I/O Processor Capacity | 1024 I/O |
| Analogue I/O Processor Capacity | 80 I/O |
| Number of Application Specific Channels | 24 |
| Port | Ethernet 10BASE-T/100BASE-TX |
| Current Consumption | 1650 mA at 5 V DC |
| Net Weight | 0.042 kg |
| Ambient Air Temperature for Operation | 0…60 °C |
| Ambient Air Temperature for Storage | -25…70 °C |
