WEG NACFW110031T40N1Z

Weg Nacfw110031T40N1Z

WEG NACFW110031T40N1Z

The WEG NACFW110031T40N1Z is a variable frequency drive (VFD) from the illustrious CFW11 series. This variable frequency drive (VFD) is excellent for harsh industrial settings because it improves the efficiency and performance of three-phase induction motors and permanent magnet synchronous motors.

Technical Specifications:

The WEG NACFW110031T40N1Z is compatible with three-phase power supply systems and operates within an input voltage range of 380-480V AC. It's motor power ratings of 20 HP on regular duty and 15 HP on heavy-duty, guaranteeing versatility and resilience, which allows it to handle differing load circumstances. Its capacity to efficiently manage large electrical loads is demonstrated by its rated currents of 31A for regular duty and 25A for heavy duty.

This VFD is suitable for most industrial settings due to its NEMA 1 casing. The unit's integrated dynamic brake transistor improves braking in applications that need quick motor stops. The drive's UL 508 C and IEC 60947-4-2 overload protection make it safe even without a safety stop.

One of its advantages is that the NACFW110031T40N1Z meets IEC61000-3-12 harmonics criteria with its inbuilt DC link inductors. This eliminates the need for an external line reactance and keeps the drive within harmonic limits. The USB connector lets you upgrade the firmware and utilize SUPERDRIVE programming and monitoring software with the VFD.

A backlit graphic display with soft keys facilitating inverter programming and operation characterizes the NACFW110031T40N1Z's user-machine interface (HMI). A built-in memory card further increases the drive's usability in complicated automation setups by letting customers develop soft-PLC functionalities without additional PLCs.

Installation and Maintenance:

Installing the NACFW110031T40N1Z is a breeze because of its plug-and-play design, which cuts down on setup time and the requirement for specialized technical knowledge. A guided start-up process is also available for this VFD, which makes initial user programming easier and guarantees a smooth commissioning phase. To safeguard the IGBTs and guarantee peak performance, the drive's clever thermal management system keeps tabs on the heatsink and the internal air temperature.

The heatsink fan's automatic control and built-in speed sensor provide an additional safeguard, and the fan is simple to remove for cleaning and maintenance. This capability is instrumental in dusty and debris-filled industrial settings, where performance might be negatively affected.

Additional Features:

The NACFW110031T40N1Z has several high-tech characteristics that make it more reliable and valuable. Its real-time clock is a must-have feature for time-sensitive apps and precise event logging. Users can gain deep insights into the drive's operational parameters and facilitate troubleshooting using the TRACE/SCOPE feature, which aids with start-up and system diagnostics.

The VFD is lightweight (about 23 lbs) and has small (about 13.9 x 7.5 x 9.0 inches) proportions, which make it easy to work with and incorporate into current systems.

Frequently Asked Questions:

Is there a brake system on the WEG NACFW110031T40N1Z?

The WEG NACFW110031T40N1Z does have improved braking capabilities thanks to its integrated dynamic brake transistor. Applications requiring quick motor stops will greatly benefit since they enhance safety and performance.

How does the WEG NACFW110031T40N1Z meet harmonic standards?

Due to its built-in DC link inductors, the WEG NACFW110031T40N1Z satisfies IEC61000-3-12 harmonics criteria and operates smoothly without external line reactance.

The WEG NACFW110031T40N1Z has what user interface features?

A lighted graphic display and soft keys make programming and operation accessible on the WEG NACFW110031T40N1Z. It also has a memory card for soft-PLC capabilities, making it useful for automation.

Product Specifications Table:

Attribute Specification
Input Voltage 380-480 V AC
Input Phases Three-phase
Motor Power (Normal Duty) 20 HP
Motor Power (Heavy Duty) 15 HP
Rated Current (Normal Duty) 31 A
Rated Current (Heavy Duty) 25 A
Enclosure Type NEMA 1
Dynamic Braking Included
Dimensions (HxWxD) 13.9 x 7.5 x 9.0 inches
Weight 23 lbs

WEG NACFW110031T40N1Z

Regular price
$2,990.00
Sale price
$2,990.00
We currently have 1 in stock.
