Yaskawa CIMR-AU2A0056FAA

Yaskawa Cimr-Au2A0056Faa
Yaskawa Cimr-Au2A0056Faa

Yaskawa CIMR-AU2A0056FAA

The Yaskawa CIMR-AU2A0056FAA is a robust and reliable A1000 series VFD. This high-performance device controls manufacturing AC motor speeds. The CIMR-AU2A0056FAA's reliability and versatility allow it to operate efficiently in many challenging conditions.

Technical Specifications:

Since it runs at 200-240 VAC, the Yaskawa CIMR-AU2A0056FAA accepts single-phase and three-phase inputs. The 20 HP horsepower rating makes this product ideal for demanding industrial applications. This VFD's 56 Amp current rating ensures stable operation under high loads.

This drive operates from 0.01 to 400 Hz. For activities requiring varying operational speeds, this wide range is essential for accurate motor speed control. This variable frequency drive (VFD) supports V/f Control, Open Loop Vector Control (OLV), and Closed Loop Vector Control, making it versatile enough for many applications.

Starting torque can reach 150% at 3 Hz with V/f and V/f w/PG and 200% at 0.3 Hz with OLV. This ensures the drive starts smoothly, even under enormous loads. With a ratio of 1:200 for OLV and a range of 1:1500 for CLV, the control mechanism provides fine speed adjustments, but the range varies.

The CIMR-AU2A0056FAA is suited for many industrial applications due to its NEMA 1 enclosure and 13.39" x 7.09" x 7.36" size. The interface's unique LCD screen and keypad simplify setup and monitoring. The drive's RS-422 and RS-485 compatibility improves communication and makes integrating with industrial control systems easy.

Control and Performance Features:

The Yaskawa CIMR-AU2A0056FAA has advanced control functions, including OLV/PM and CLV/PM. These tactics help the driver regulate the motor precisely, even when the load fluctuates. Digital inputs provide a frequency setting resolution of 0.01 Hz, whereas analog inputs have 1/2048 of the highest output frequency setting for fine-tuning.

It ensures adequate deceleration, making it vital for applications that need swift stopping. A speed control accuracy of ±0.2% for OLV and ±0.02% for CLV ensures constant motor speed despite operating circumstances.

Protection and Safety Features:

The protective system includes an electrical thermal overload relay to avoid motor overheating. The drive's transient overcurrent protection circuit shuts power if the load current exceeds 200% of the heavy-duty rating.

Overvoltage protection stops the drive if the DC bus voltage exceeds limitations to prolong device life. In undervoltage, the drive stops to protect the motor and drive components. Built-in braking transistors improve drive braking for models with specific power ratings.

Drive input and output options are provided. It has three analog inputs, two programmable analog outputs, eight digital and four digital outputs. These properties enable huge configurability and interoperability with other control systems. The principal speed frequency reference can be set with DC -10 to +10 V, making it compatible with many control systems.

Frequently Asked Questions:

What is the rated current of the Yaskawa CIMR-AU2A0056FAA, and how does it safeguard the motor?

With a rated current of 56 Amps and an electronic thermal overload relay, the Yaskawa CIMR-AU2A0056FAA is a reliable motor protector that can withstand demanding applications.

How high is the digital input resolution on the Yaskawa CIMR-AU2A0056FAA, and what is its starting torque capability?

To guarantee effective performance and accurate control, the Yaskawa CIMR-AU2A0056FAA has a digital input resolution of 0.01 Hz and a starting torque of 150% at 3 Hz (V/f).

How does the Yaskawa CIMR-AU2A0056FAA deal with overvoltage protection, and what braking measures does it include?

With the addition of a resistor, the Yaskawa CIMR-AU2A0056FAA's braking capabilities can be enhanced to 125% from 20%. It takes care of overvoltage protection by turning off the power when the DC bus voltage exceeds certain limits, ensuring everything runs smoothly.

Product Specifications Table:

Attribute Specification
Power Rating 20 HP
Voltage Range 200-240 VAC
Rated Current 56 Amps
Frequency Range 0.01 to 400 Hz
Control Methods V/f, OLV, CLV, OLV/PM, CLV/PM
Starting Torque 150% at 3 Hz (V/f), 200% at 0.3 Hz (OLV)
Speed Control Range 1:200 (OLV), 1:1500 (CLV)
Dimensions 13.39" x 7.09" x 7.36"
Enclosure NEMA 1
Analog Inputs 3

Yaskawa CIMR-AU2A0056FAA

Regular price
$2,690.00
Sale price
$2,690.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Yaskawa CIMR-AU2A0056FAA

The Yaskawa CIMR-AU2A0056FAA is a robust and reliable A1000 series VFD. This high-performance device controls manufacturing AC motor speeds. The CIMR-AU2A0056FAA's reliability and versatility allow it to operate efficiently in many challenging conditions.

Technical Specifications:

Since it runs at 200-240 VAC, the Yaskawa CIMR-AU2A0056FAA accepts single-phase and three-phase inputs. The 20 HP horsepower rating makes this product ideal for demanding industrial applications. This VFD's 56 Amp current rating ensures stable operation under high loads.

This drive operates from 0.01 to 400 Hz. For activities requiring varying operational speeds, this wide range is essential for accurate motor speed control. This variable frequency drive (VFD) supports V/f Control, Open Loop Vector Control (OLV), and Closed Loop Vector Control, making it versatile enough for many applications.

Starting torque can reach 150% at 3 Hz with V/f and V/f w/PG and 200% at 0.3 Hz with OLV. This ensures the drive starts smoothly, even under enormous loads. With a ratio of 1:200 for OLV and a range of 1:1500 for CLV, the control mechanism provides fine speed adjustments, but the range varies.

The CIMR-AU2A0056FAA is suited for many industrial applications due to its NEMA 1 enclosure and 13.39" x 7.09" x 7.36" size. The interface's unique LCD screen and keypad simplify setup and monitoring. The drive's RS-422 and RS-485 compatibility improves communication and makes integrating with industrial control systems easy.

Control and Performance Features:

The Yaskawa CIMR-AU2A0056FAA has advanced control functions, including OLV/PM and CLV/PM. These tactics help the driver regulate the motor precisely, even when the load fluctuates. Digital inputs provide a frequency setting resolution of 0.01 Hz, whereas analog inputs have 1/2048 of the highest output frequency setting for fine-tuning.

It ensures adequate deceleration, making it vital for applications that need swift stopping. A speed control accuracy of ±0.2% for OLV and ±0.02% for CLV ensures constant motor speed despite operating circumstances.

Protection and Safety Features:

The protective system includes an electrical thermal overload relay to avoid motor overheating. The drive's transient overcurrent protection circuit shuts power if the load current exceeds 200% of the heavy-duty rating.

Overvoltage protection stops the drive if the DC bus voltage exceeds limitations to prolong device life. In undervoltage, the drive stops to protect the motor and drive components. Built-in braking transistors improve drive braking for models with specific power ratings.

Drive input and output options are provided. It has three analog inputs, two programmable analog outputs, eight digital and four digital outputs. These properties enable huge configurability and interoperability with other control systems. The principal speed frequency reference can be set with DC -10 to +10 V, making it compatible with many control systems.

Frequently Asked Questions:

What is the rated current of the Yaskawa CIMR-AU2A0056FAA, and how does it safeguard the motor?

With a rated current of 56 Amps and an electronic thermal overload relay, the Yaskawa CIMR-AU2A0056FAA is a reliable motor protector that can withstand demanding applications.

How high is the digital input resolution on the Yaskawa CIMR-AU2A0056FAA, and what is its starting torque capability?

To guarantee effective performance and accurate control, the Yaskawa CIMR-AU2A0056FAA has a digital input resolution of 0.01 Hz and a starting torque of 150% at 3 Hz (V/f).

How does the Yaskawa CIMR-AU2A0056FAA deal with overvoltage protection, and what braking measures does it include?

With the addition of a resistor, the Yaskawa CIMR-AU2A0056FAA's braking capabilities can be enhanced to 125% from 20%. It takes care of overvoltage protection by turning off the power when the DC bus voltage exceeds certain limits, ensuring everything runs smoothly.

Product Specifications Table:

Attribute Specification
Power Rating 20 HP
Voltage Range 200-240 VAC
Rated Current 56 Amps
Frequency Range 0.01 to 400 Hz
Control Methods V/f, OLV, CLV, OLV/PM, CLV/PM
Starting Torque 150% at 3 Hz (V/f), 200% at 0.3 Hz (OLV)
Speed Control Range 1:200 (OLV), 1:1500 (CLV)
Dimensions 13.39" x 7.09" x 7.36"
Enclosure NEMA 1
Analog Inputs 3
