MICROLOGIX 1200
24V DC POWER
(20) STANDARD 24V DC AND (4) FAST 24V DC DIGITAL INPUTS
(8) RELAY OUTPUTS
(7) STANDARD 24V DC FETOUTPUTS
(1) FAST 24V DC FET OUTPUT
Technical Specifications
Manufacturer
Rockwell Automation
Brand
Allen-Bradley
Series
MicroLogix 1200
Part Number/Catalog No.
1762-L40BXB
Product Type
Programmable Controller
Power Supply
24V dc( -15%, +10%)Class 2SELV
No. of Inputs
Twenty-Four (24)
Outputs
(8) Relay, (7) 24 Volt DC FET, and (1) High-Speed 24 Volt DC FET
Input Power
24 Volts DC
No. of Outputs
Sixteen(16)
Inputs
(20) 24 Volt DC and (4) Fast 24 Volt DC
Input Circuit Type
24 Volts DC Sink/Source
Power Supply Voltage
100 to 240 Volts
Output Circuit Type
Relay / FET
Weight
2.4 pounds
Relay Contact Rating
24-125VDC; 120-240VAC
Heat Dissipation
21 Watts
Mechanical Cycles
20,000,000
Operating Frequency
0 to 20 kHertz
Load Current
10A, minimum
Dimensions
Height: 90 mm 104 mm (with DIN latch open); Width: 160 mm; Depth: 87 mm
Ambient Operating Temp
0 to 55 degrees Celsius
Power Supply Usage
82 VA
Power supply inrush current
120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms
Programming Software
RSLogix 500
