The Allen-Bradley 2098-DSD-020-SE Digital Servo Drive is a part of the Ultra3000 series, organized for high-performance motion control applications. This drive is widely acclaimed for its dependability and versatility, making it a prevalent choice in control systems due to its potent performance and adaptability.
Technical Specifications:
The Allen-Bradley 2098-DSD-020-SE Digital Servo Drive features an 18 Amps Root Mean Square (RMS) nominal input current. This parameter indicates the influential current that the device draws from the AC power supply under normal operating conditions.
Despite its cutting-edge capabilities, the 2098-DSD-020-SE does not include internal shunt resistance. Shunt resistors are typically used to manage excess current by diverting it away from critical components.
The bus capacitance of the 2098-DSD-020-SE is rated at 1880 µF. Bus capacitance plays a crucial role in stabilizing the DC bus voltage, which is fundamental for the consistent performance of the servo drive. The 2098-DSD-020-SE can deliver up to 30 Amps of intermittent output current for improved performance without causing thermal overload.
Additionally, the drive provides a steady output current of 10 Amps. Continuous current denotes the steady-state current that the drive can supply over an extended period without overheating. The Allen-Bradley 2098-DSD-020-SE Digital Drive is designed to function in a single-phase configuration with an intake voltage of 100 to 240V AC.
One of the critical protection features of the 2098-DSD-020-SE is its bus overvoltage rating of 400 volts DC. This specification exhibits the maximum voltage level the DC bus can tolerate before potentially causing damage to the drive or connected components.
Ambient Conditions:
The Allen-Bradley 2098-DSD-020-SE is engineered to serve efficiently within an operating temperature range from zero to 55 degrees Celsius. This wide temperature range assures the drive can perform reliably in various environmental conditions, from cooler, controlled indoor settings to warmer, more challenging industrial environments.
Additionally, the consolidated size of the 2098-DSD-020-SE module contributes significantly to its versatility and ease of transportation. Its small footprint makes it easier to install in space-constrained areas, which is often a requirement in modern industrial setups where maximizing available space is essential.
Pre-Configuration Checklist for the 2098-DSD-020-SE:
Before configuring the Allen-Bradley 2098-DSD-020-SE Digital Servo Drive, ensure that all terminal connections for both the transmitting and receiving ends are correctly established. This effort is paramount for the accurate functioning and communication of the drive.
The 2098-DSD-020-SE features a 7-segment display panel that provides real-time status updates of its operations. For instance, if the panel displays alternating green and red flashes, it indicates that the drive is in the process of establishing communication. Proper connection and monitoring of these indicators are essential for successful setup and operation.
Frequently Asked Questions:
Does the Allen-Bradley 2098-DSD-020-SE have an auxiliary power supply?
No, the Allen-Bradley 2098-DSD-020-SE does not include an auxiliary power supply. The drive relies exclusively on its primary power input for all operations.
What communication interface does the 2098-DSD-020-SE use, and what are its benefits?
The 2098-DSD-020-SE utilizes the SERCOS (Serial Real-time Communication System) interface. SERCOS is a widely adopted industrial automation interface known for its high-speed, real-time communication capabilities.
What are the dimensions of the Allen-Bradley 2098-DSD-020-SE?
The dimensions of the Allen-Bradley 2098-DSD-020-SE are 7.8 x 5.68 x 3.89 inches. These compact proportions make the drive relatively small and easy to handle, simplifying its installation in tight or restrained spaces.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Ultra 3000 |
| Horsepower | 2.68 HP (2 kW output power) |
| Voltage | 120/240V AC input voltage |
| Dimensions | 7.8 x 5.68 3.89 x in (198.12 x 144.27 x 98.1 mm) |
| Communication Interface | SERCOS |
| Bus Capacitance | 1880 µF |
| Ambient Temperature Range | 0-55o C, |
| Bus Overvoltage | 400V DC |
| Input/Output Frequency Range | 50/60 Hz |
| Mounting Type | Panel-mounted |
