Allen-Bradley 2098-DSD-HV100-SE
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2098-DSD-HV100-SE
The Allen-Bradley 2098-DSD-HV100-SE from the Ultra 3000 series is a high-performance digital servo drive for demanding industrial applications. It guarantees meticulous motion control and supports the SERCOS interface for improved synchronization and real-time communication in multi-axis systems.
Technical Features:
The Allen-Bradley 2098-DSD-HV100-SE is designed with distinctive electrical characteristics to provide optimal performance and protection. One crucial specification is its shunt regulation voltage, which helps manage excess energy during braking operations. The drive's shunt activates at 402 volts DC, effectively dissipating excess power and maintaining system stability.
The drive accommodates different power supply configurations regarding input current requirements. With a nominal input of 230 volts AC, the drive operates at a current of 0.5 amps RMS. This configuration is typical for many industrial environments, balancing power efficiency and performance.
The drive operates with a nominal input of 115 volts AC, drawing 1.0 amps RMS for lower voltage applications. This flexibility allows the 2098-DSD-HV100-SE to integrate seamlessly with various electrical systems, ensuring compatibility with existing infrastructure and enhancing its utility in diverse industrial settings.
The Allen-Bradley 2098-DSD-HV100-SE is designed for high performance in demanding applications, managing substantial electrical loads. It delivers up to 23 amps (0-peak) for intermittent operations, enabling it to handle rapid acceleration and deceleration during dynamic motion control tasks.
Additionally, the 2098-DSD-HV100-SE supports a continuous output current of 46 amps (0-peak). This continuous current rating ensures that the drive can maintain high power output over extended periods without overheating or suffering from performance degradation.
The Allen-Bradley 2098-DSD-HV100-SE drive is built with robust electrical specifications to ensure efficient and reliable operation. One of the critical components within this drive is the bus capacitance, rated at 2820 microfarads (?F).
Additionally, the bus overvoltage protection is an essential safety feature of the 2098-DSD-HV100-SE. The drive is designed to handle a bus overvoltage threshold of 452 volts DC. This protection mechanism prevents damage to the drive and connected equipment by ensuring the voltage does not exceed safe operating limits.
Operating Conditions:
The Allen-Bradley 2098-DSD-HV100-SE drive efficiently operates from 0 to 55 degrees Celsius, ensuring reliable performance in various industrial environments.
The 2098-DSD-HV100-SE operates effectively in 5%-95% humidity without condensation. Furthermore, the drive is engineered to withstand an operational shock of 15G, making it resilient to sudden impacts or jolts that may occur in industrial settings.
Terminal Connections and Functions:
The Allen-Bradley 2098-DSD-HV100-SE servo drive has front panel terminals TB1, TB2, and CN1. TB1, an 11-point terminal strip, supports motor connection, power supply, auxiliary power, DC output, and earthing.
TB2 is specifically designated for connecting external passive shunt devices. This terminal manages excess energy during braking operations, ensuring safe and efficient power dissipation.
CN1, on the other hand, is assigned for the Normally Open (NO) relay output. This terminal is typically used for signaling and control, allowing integration with other control systems or safety interlocks.
Frequently Asked Questions:
What is the purpose of the internal shunt resistance in the 2098-DSD-HV100-SE servo drive?
The internal shunt resistance in the Allen-Bradley 2098-DSD-HV100-SE rated at 40 ohms, is critical in managing excess energy during braking operations.
How does the Allen-Bradley 2098-DSD-HV100-SE handle vibrations, and why is this important?
The 2098-DSD-HV100-SE is designed to withstand vibrations up to 2.5G. This capability is crucial for maintaining the drive's reliability and performance in industrial environments.
Does the Allen-Bradley 2098-DSD-HV100-SE have an auxiliary power supply?
Yes, the Allen-Bradley 2098-DSD-HV100-SE has an auxiliary power supply. The inclusion of an auxiliary power supply offers several benefits.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Ultra 3000 |
| Horsepower | 10 kW (approximately 13.4 HP) |
| Voltage | 230 to 480 volts AC, three-phase |
| Dimensions | 9.54 x 14.2 x 5.97 in (242.2 x 360.7 x 151.6 mm) |
| Communication Interface | SERCOS (Serial Real-Time Communication System) |
| Software Compatibility | Ultraware software |
| Ambient Temperature Range | 0 to 55 degrees Celsius |
| Control Method | Digital control via SERCOS interface |
| Input/Output Frequency Range | 47 to 63 Hz (input), 0 to 500 Hz (output) |
| Mounting Type | Panel mount |
