Allen-Bradley 2098-DSD-HV220-SE

Allen-Bradley 2098-Dsd-Hv220-Se
Allen-Bradley 2098-Dsd-Hv220-Se

Allen-Bradley 2098-DSD-HV220-SE

The Allen-Bradley 2098-DSD-HV220-SE, a high-voltage digital servo drive from Rockwell Automation's Ultra 3000 series, is renowned for its enduring design and reliable performance in challenging industrial settings. Engineered for high efficiency, it is essential for precise control and increased productivity in automation systems.

Technical Specifications:

The Allen-Bradley 2098-DSD-HV220-SE servo drive offers a peak intermittent output current of 94 amps, enabling it to handle sudden, high-demand tasks efficiently. This feature ensures the drive can manage short bursts of power needed in industrial applications without sacrificing performance.

For continuous operation, the 2098-DSD-HV220-SE delivers a steady output current of 47 amps. This continuous current rating is crucial for maintaining consistent motor performance over extended periods, ensuring the reliability and stability of the system.

Additionally, the servo drive incorporates an auxiliary power supply feature. This auxiliary power supply is designed to support the drive's digital I/O functions, ensuring that the control and communication components remain operational even if the main power supply is disrupted.

The Allen-Bradley 2098-DSD-HV220-SE servo drive is designed with a nominal input current of 28 amps Root Mean Square (RMS). This specification ensures that the drive receives a consistent and stable supply of current, which is essential for its efficient operation.

The servo drive also functions within an input frequency range of 47 to 63 Hz. This comprehensive frequency range allows the drive to be compatible with different power systems globally, accommodating variations in electrical grid standards.

The 2098-DSD-HV220-SE servo drive contains an internal shunt resistor with a resistance of 20 ohms. This internal shunt resistor plays a crucial role in managing the drive's energy dissipation, specifically during braking operations or deceleration periods.

Ambient Conditions:

The Allen-Bradley 2098-DSD-HV220-SE Ultra3000-SE Drive works effectively in temperatures between 0 and 55°C, providing safe and reliable performance.

The drive also withstands up to 95% non-condensing relative humidity, protecting against moisture-related issues like corrosion and short-circuiting.

Applications of Allen-Bradley 2098-DSD-HV220-SE:

The Allen-Bradley 2098-DSD-HV220-SE Ultra 3000-SE Digital Servo Drive is used in industrial applications demanding precise motion control, like robotics, automated assembly lines, and CNC machinery. Its robust design and high output power make it perfect for complex multi-axis motion control systems.

Additionally, it is used in packaging, printing, and material handling systems, where synchronized motor operation is essential. The drive's compatibility with the SERCOS interface ensures seamless integration with higher-level controllers, enhancing industrial automation efficiency.

Frequently Asked Questions:

What are the physical dimensions of the Allen-Bradley 2098-DSD-HV220-SE Servo Drive?

The Allen-Bradley 2098-DSD-HV220-SE Ultra 3000-SE Digital Servo Drive has specific physical dimensions designed to fit seamlessly into various industrial settings. The dimensions are 9.54 inches in width, 15.43 inches in height, and 8.0 inches in depth (242.2 x 391.8 x 203.2 mm).

What features does the SERCOS interface offer for the 2098-DSD-HV220-SE Drive?

The 2098-DSD-HV220-SE servo drive features a SERCOS (Serial Real-time Communication System) interface, enabling high-speed, real-time communication with control devices. This ensures precise synchronization and coordination in multi-axis motion control applications, making it ideal for advanced industrial automation.

How does the bus capacitance of 1880 µF benefit the Allen-Bradley 2098-DSD-HV220-SE?

The Allen-Bradley 2098-DSD-HV220-SE Ultra 3000-SE Digital Servo Drive features a bus capacitance of 1880 microfarads (µF). This high capacitance value plays a vital role in the drive's performance by stabilizing the internal DC bus voltage, which is crucial for maintaining consistent power delivery to the servo motor.

Product Specifications Table

Attribute Specifications
Series Ultra 3000
Continuous Output Current 47A
Voltage 230-480 V AC (3-Phase)
Dimensions 9.54 x 15.43 x 8.0 in (242.2 x 391.8 x 203.2 mm)
Communication Interface SERCOS
Power Rating 22 kW
Ambient Temperature Range 0 to 55 degrees Celsius
Control Method Digital Servo Control
Input/Output Frequency Range 47-63 Hz (Input)
Mounting Type Panel Mount

Allen-Bradley 2098-DSD-HV220-SE

Regular price
Sale price
$2,490.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
