Allen-Bradley 22B-D017N104

The Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive is manufactured by Rockwell Automation. The model is a versatile and sturdy drive made for industrial applications in situations where precise motor control is needed.

Technical Specifications:

The model operates at three-phase, 380 ‚ 480 V AC, delivering 7.5 kW (10 HP) with a 17 amp output. It features sensorless vector control, an IP20 (Open) rating, and supports a 0 - 400 Hz frequency range. Compact (180 mm height, 136 mm depth), it operates in temperatures ranging from 0 °C to 50 °C. Its overload protection is advanced and ensures reliable motor control.

It can deliver up to 150 % of rated torque, during demanding startup conditions. Its time settings are adjustable from 0.1 to 3600 seconds, which enables its smooth start-up and stop operations.

Operational and Installation Parameters:

Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive is designed for easy installation and integration into various industrial environments. It is space-efficient and compact, making it simple to install in industrial environments. Its LED display and digital keyboard make setup and monitoring easier.

It supports RS485 communication, facilitating integration with other automation systems for remote control and diagnostics. The installation environment should be clean and dry, free from corrosive gases and excessive dust, and grounding should be appropriate to reduce electromagnetic interference.

Features and performance:

The Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive uses an advanced programming system because it has a user-friendly LCD with a keypad that makes it easy to monitor and configurations. It has a DIN rail or panel mount. It has a good environmental rating as a NEMA/UL Type 1 enclosure, suitable for indoor use. Moreover, it has sensorless vector control which is V/Hz control.

This drive has a sensorless vector control with a 40:1 speed control range. Its energy efficiency is optimized with adjustable energy parameters. For the applications of process control, it has built-in PID control.

Safety Precautions:

While using the Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive, it is very important to follow safety precautions and guidelines to prevent equipment damage and accidents. The drive has built-in overload protection that prevents damage from excessive current flow. Configure the overload settings according to motor specifications.

Ensure all power connections are made by qualified personnel. Disconnect the power before servicing it to prevent electrical shock. The drive includes a built-in dynamic brake chopper. Ensure the braking resistor is correctly sized and installed to facilitate effective braking and prevent drive damage. To prevent overheating, maintain proper ventilation. To avoid contamination, install the drive in a clean environment.

Frequently Asked Questions:

What is the output power and current of the Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive?

The Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive delivers an output power of 7.5 kW (10 HP) and a nominal output current of 17 amps, ensuring robust performance for various industrial applications.

What communication options are available on the Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive?

The drive features an RS485 communication interface, that allows for seamless integration with other automation systems for remote monitoring and control.

What are the temperature range and mounting for the Allen-Bradley 22B-D017N104 PowerFlex 40 Variable frequency drive?

The Allen-Bradley 22B-D017N104 operates within a temperature range of 0 °C to 50 °C and must be installed in a panel mount configuration. The model is suitable for various industrial environments.
