Allen-Bradley 22B-D6P0N104
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚… here.
- 22BD6P0N104
- AC DRIVE
- ADJUSTABLE FREQUENCY
- POWERFLEX 40
- 480 VAC
- 3 PHASE
- 6 AMP
- 2.2 KW
- 3 HP
- PANEL MOUNT - IP 20 NEMA TYPE OPEN
- FIXED KEYPAD
- NOT FILTERED
- STANDARD BRAKE
Repair & Service
Quick Repairs and Great Service
Quick Search
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 22B-D6P0N104
| Filter | Without CE Compliant Filter |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer: | |
| Input Voltage: | 380-480VAC |
| Input Phase: | 3-Phase |
| Rated Current output: | 6.0 A |
| Rated Power: | 2.2 kW (3.0 HP) |
| Installation: | Panel Mount |
| Enclosure Rating: | IP20 / NEMA UL Type Open |
| Keypad: | LED Keypad |
| Built-in Communication port: | RS485 |
| I/O Terminal: | Discrete Inputs: 3 fixed for START/STOP/REV; 4 Fully Programmble Discrete Outputs: 4 fully programmable; Analog Input: 2 0…10V or 4…20 mA (unipolar) 1 +/- 100V (bipolar) Discrete Output: 1 - N.O/N.C. dry contact; 2 Digital / Optocoupler |
| Part Number/Catalog No. | 22B-D6P0N104 |
| Product Line | Powerflex 40 |
| Product Type | Adjustable Frequency Drive |
| Voltage | 480 Volts AC |
| Enclosure | Panel Mount - IP20, NEMA/UL Type Open |
| Horsepower | 3 Horsepower |
| Amperage | 6.0 Amps |
| Phase | 3 Phase |
| Communication | RS-485 |
| Input Type | Keypad |
| Frame Size | 8 |
| UPC | 820919078569 |
