Allen-Bradley 25B-V4P8N104

Allen-Bradley 25B-V4P8N104

Allen-Bradley 25B-V4P8N104

The Allen-Bradley 25B-V4P8N104 is a highly adaptable PowerFlex 525 series frequency drive engineered to deliver effective motor control in a variety of industrial settings. This drive is renowned for its sophisticated features and dependable performance, making it an excellent choice for optimizing automation systems while simultaneously guaranteeing operational safety and energy efficiency.

Technical Specifications:

The Allen-Bradley 25B-V4P8N104 drive requires 120VAC, single-phase electricity, and runs at 47-63 Hz. This drive can handle heavy-duty and regular activities with its 0.75 kW (1.0 HP) output capacity, making it suitable for many industrial needs. Integrating an EMC filter reduces electrical noise and ensures electromagnetic compatibility, improving system dependability.

The inbuilt Human Interface Module (HIM) on this disk has a local operating keypad for easy configuration and control. The LCD readout enables real-time drive status monitoring and error diagnostics, helping to resolve difficulties and maintain operating efficiency. The output voltage ranges from 0-230VAC with a three-phase output and 4.8 A current capacity, guaranteeing dependable performance in many applications.

The Allen-Bradley 25B-V4P8N104 's IP20 NEMA/Open Type enclosure makes installation and integration easy. Frame size B fits common enclosures, ensuring compatibility with current installations. The drive also has a standard interface module for control and communication.

Control Features:

Advanced positioning control features, such as PointStop and point-to-point positioning modes, are essential for precision-driven applications, as provided by the Allen-Bradley 25B-V4P8N104 . When a supplementary encoder card is installed, the drive supports closed-loop feedback, which allows for precise motor control. The embedded Ethernet/IP interface is a critical component of contemporary industrial automation systems, as it enables the integration of control, data collection, and configuration over a network.

The drive's versatility in complex configurations is further enhanced by its integral RS485/DSI communications, which enable a multi-drop network configuration. This comprehensive communication capability guarantees the seamless integration of a variety of control systems and devices, thereby enhancing the overall performance of the system.

Built-In Safety:

The Allen-Bradley 25B-V4P8N104 is designed with safety as a top priority. Safety features are integrated into the mechanism to safeguard both personnel and apparatus. It provides the capability to operate at half the line voltage in the event of a power outage or low voltage, thereby guaranteeing a continuous drive output for critical applications. The Safe-Torque-Off function is intended to prevent the drive from completely closing down and to improve operational safety by removing rotational power when the circuit is triggered.

The requirement for additional installation space and wiring is reduced by embedded safety features, which streamlines the setup process. Compliance with stringent safety requirements is guaranteed by this AC drive, which meets ISO 13849-1 standards and has a safety classification of SIL 2/PLd. The Allen-Bradley 25B-V4P8N104 is a dependable option for applications that necessitate operational integrity and high safety standards due to the presence of these built-in safety mechanisms.

Frequently Asked Questions:

What are the input voltage and output current of the Allen-Bradley 25B-V4P8N104 ?

The Allen-Bradley 25B-V4P8N104 functions on a 120VAC single-phase voltage input and generates an output current of 4.8 A. This guarantees consistent performance in a variety of industrial applications.

What are the control features of the Allen-Bradley 25B-V4P8N104 ?

The 25B-V4P8N104 provides closed-loop feedback with an additional encoder card, as well as point-to-point and point-stop positioning modes. Automation is improved by these features, which also provide precise motor control.

In what manner does the Allen-Bradley 25B-V4P8N104 guarantee operational safety?

A Safe-Torque-Off function and 1/2 line voltage operation are included in the 25B-V4P8N104 for critical applications. These safety features guarantee operational integrity by safeguarding personnel and equipment.

Product Specifications Table:

Attributes Specification
Manufacturer Allen Bradley
Input Voltage 120VAC, 1-phase
Frequency Range 47-63 Hz
Output Power 0.75 kW (1.0 HP)
Output Voltage 0-230VAC
Output Current 4.8 A
Output Phase 3-Phase
Enclosure Type IP20 NEMA/Open Type
Embedded Filter EMC Filter
Safety Ratings ISO 13849-1, SIL 2/PLd

Allen-Bradley 25B-V4P8N104

Regular price
Sale price
$1,690.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 25B-V4P8N104

The Allen-Bradley 25B-V4P8N104 is a highly adaptable PowerFlex 525 series frequency drive engineered to deliver effective motor control in a variety of industrial settings. This drive is renowned for its sophisticated features and dependable performance, making it an excellent choice for optimizing automation systems while simultaneously guaranteeing operational safety and energy efficiency.

Technical Specifications:

The Allen-Bradley 25B-V4P8N104 drive requires 120VAC, single-phase electricity, and runs at 47-63 Hz. This drive can handle heavy-duty and regular activities with its 0.75 kW (1.0 HP) output capacity, making it suitable for many industrial needs. Integrating an EMC filter reduces electrical noise and ensures electromagnetic compatibility, improving system dependability.

The inbuilt Human Interface Module (HIM) on this disk has a local operating keypad for easy configuration and control. The LCD readout enables real-time drive status monitoring and error diagnostics, helping to resolve difficulties and maintain operating efficiency. The output voltage ranges from 0-230VAC with a three-phase output and 4.8 A current capacity, guaranteeing dependable performance in many applications.

The Allen-Bradley 25B-V4P8N104 's IP20 NEMA/Open Type enclosure makes installation and integration easy. Frame size B fits common enclosures, ensuring compatibility with current installations. The drive also has a standard interface module for control and communication.

Control Features:

Advanced positioning control features, such as PointStop and point-to-point positioning modes, are essential for precision-driven applications, as provided by the Allen-Bradley 25B-V4P8N104 . When a supplementary encoder card is installed, the drive supports closed-loop feedback, which allows for precise motor control. The embedded Ethernet/IP interface is a critical component of contemporary industrial automation systems, as it enables the integration of control, data collection, and configuration over a network.

The drive's versatility in complex configurations is further enhanced by its integral RS485/DSI communications, which enable a multi-drop network configuration. This comprehensive communication capability guarantees the seamless integration of a variety of control systems and devices, thereby enhancing the overall performance of the system.

Built-In Safety:

The Allen-Bradley 25B-V4P8N104 is designed with safety as a top priority. Safety features are integrated into the mechanism to safeguard both personnel and apparatus. It provides the capability to operate at half the line voltage in the event of a power outage or low voltage, thereby guaranteeing a continuous drive output for critical applications. The Safe-Torque-Off function is intended to prevent the drive from completely closing down and to improve operational safety by removing rotational power when the circuit is triggered.

The requirement for additional installation space and wiring is reduced by embedded safety features, which streamlines the setup process. Compliance with stringent safety requirements is guaranteed by this AC drive, which meets ISO 13849-1 standards and has a safety classification of SIL 2/PLd. The Allen-Bradley 25B-V4P8N104 is a dependable option for applications that necessitate operational integrity and high safety standards due to the presence of these built-in safety mechanisms.

Frequently Asked Questions:

What are the input voltage and output current of the Allen-Bradley 25B-V4P8N104 ?

The Allen-Bradley 25B-V4P8N104 functions on a 120VAC single-phase voltage input and generates an output current of 4.8 A. This guarantees consistent performance in a variety of industrial applications.

What are the control features of the Allen-Bradley 25B-V4P8N104 ?

The 25B-V4P8N104 provides closed-loop feedback with an additional encoder card, as well as point-to-point and point-stop positioning modes. Automation is improved by these features, which also provide precise motor control.

In what manner does the Allen-Bradley 25B-V4P8N104 guarantee operational safety?

A Safe-Torque-Off function and 1/2 line voltage operation are included in the 25B-V4P8N104 for critical applications. These safety features guarantee operational integrity by safeguarding personnel and equipment.

Product Specifications Table:

Attributes Specification
Manufacturer Allen Bradley
Input Voltage 120VAC, 1-phase
Frequency Range 47-63 Hz
Output Power 0.75 kW (1.0 HP)
Output Voltage 0-230VAC
Output Current 4.8 A
Output Phase 3-Phase
Enclosure Type IP20 NEMA/Open Type
Embedded Filter EMC Filter
Safety Ratings ISO 13849-1, SIL 2/PLd
