Allen-Bradley 2711-TC1

Allen-Bradley 2711-Tc1
Allen-Bradley 2711-Tc1
Allen-Bradley 2711-Tc1

Allen-Bradley 2711-TC1

The Allen-Bradley 2711-TC1 is a part of the PanelView 1200 product line, known for its reliable performance and ease of use in demanding industrial environments. Its combination of a user-friendly touchscreen interface, robust communication capabilities, and durable construction makes it an invaluable tool for operators seeking efficient and reliable control over their industrial processes.

Technical Specifications:

This operator terminal operates within a broad input voltage range of 90-264 VAC at frequencies between 47-63 Hz, making it suitable for various power environments. Designed for industrial environments, this Allen-Bradley 2711-TC1 features a 12-inch coloured CRT display that offers a resolution of 640 x 480 pixels, ensuring clear and detailed visualization of operational data.

The touchscreen interface, divided into 120 touch cells arranged in a grid of 10 columns by 12 rows, facilitates intuitive user interactions. Each touch cell is capable of displaying two characters high by eight characters wide, optimizing both user input and display clarity.

An LED with an impressive lifespan of 100,000 hours provides its backlighting, ensuring long-term, reliable display illumination. Engineered for durability, the terminal is encased in a NEMA 12 rated enclosure, providing adequate protection against dust, dirt, and non-corrosive liquids typically found in industrial settings.

Advanced Communication Capabilities:

The Allen-Bradley 2711-TC1 excels in providing advanced communication features that enhance its integration into complex industrial systems. The inclusion of a Remote I/O (RIO) port allows seamless connectivity with a variety of industrial devices.

Additionally, the RS232 interface offers a dedicated channel for printer connections, facilitating the documentation and logging of critical operational data. These communication options ensure that the module can easily interface with other equipment.

Maintenance and Safety Protocols:

Regular maintenance of the Allen-Bradley 2711-TC1 is essential to ensure its optimal performance and longevity. Periodic inspection of the terminal should include checking for any signs of wear or damage on the touchscreen and ensuring the enclosure remains sealed.

Additionally, the LED backlight should be monitored for any signs of dimming or failure, and replacements should be made as necessary to ensure continuous operation. It's also crucial to verify that the ventilation slots are free from dust and debris to prevent overheating.

Regularly updating the terminal's firmware and software can enhance performance and address any potential vulnerabilities. Ensuring that all communication ports are secure and functioning correctly is also vital for maintaining robust connectivity within the industrial network.

Before performing any maintenance, always disconnect the Allen-Bradley 2711-TC1 from its power source to eliminate the risk of electric shock. Operators should be trained to handle the terminal safely, including proper techniques for touching the screen to avoid applying excessive force, which could damage the display.

Always use appropriate personal protective equipment (PPE) when handling the terminal, particularly in industrial settings where there might be additional hazards.

Frequently Asked Questions:

What is the operating temperature range of the Allen-Bradley 2711-TC1?

The operating temperature range of 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) further underscores its suitability for various operational conditions.

How much user memory does the Allen-Bradley 2711-TC1 have, and what does this mean for application storage?

The Allen-Bradley 2711-TC1 houses 64K of standard user memory, providing sufficient space for application storage and execution. This capacity allows for the efficient handling of various control programs and user applications.

How efficient is the power consumption of the Allen-Bradley 2711-TC1?

The Allen-Bradley 2711-TC1 features a maximum heat dissipation of 246 BTU per hour, highlighting its efficient power consumption management.

Product Specifications Table

Attribute Specifications
Series PanelView 1200
Voltage 90-264 VAC
LED Lifespan 100,000 hours
Communication Interface Remote I/O (RIO) and RS232
Weight 13.6 kg
Operating Temperature Range 0 to 50°C
Heat Dissipation 246 BTU per hour
Display size 12 inch
Touchscreen interface 640 x 480 pixels
Product Status Discontinued

Allen-Bradley 2711-TC1

Regular price
Sale price
$1,990.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 2711-TC1

The Allen-Bradley 2711-TC1 is a part of the PanelView 1200 product line, known for its reliable performance and ease of use in demanding industrial environments. Its combination of a user-friendly touchscreen interface, robust communication capabilities, and durable construction makes it an invaluable tool for operators seeking efficient and reliable control over their industrial processes.

Technical Specifications:

This operator terminal operates within a broad input voltage range of 90-264 VAC at frequencies between 47-63 Hz, making it suitable for various power environments. Designed for industrial environments, this Allen-Bradley 2711-TC1 features a 12-inch coloured CRT display that offers a resolution of 640 x 480 pixels, ensuring clear and detailed visualization of operational data.

The touchscreen interface, divided into 120 touch cells arranged in a grid of 10 columns by 12 rows, facilitates intuitive user interactions. Each touch cell is capable of displaying two characters high by eight characters wide, optimizing both user input and display clarity.

An LED with an impressive lifespan of 100,000 hours provides its backlighting, ensuring long-term, reliable display illumination. Engineered for durability, the terminal is encased in a NEMA 12 rated enclosure, providing adequate protection against dust, dirt, and non-corrosive liquids typically found in industrial settings.

Advanced Communication Capabilities:

The Allen-Bradley 2711-TC1 excels in providing advanced communication features that enhance its integration into complex industrial systems. The inclusion of a Remote I/O (RIO) port allows seamless connectivity with a variety of industrial devices.

Additionally, the RS232 interface offers a dedicated channel for printer connections, facilitating the documentation and logging of critical operational data. These communication options ensure that the module can easily interface with other equipment.

Maintenance and Safety Protocols:

Regular maintenance of the Allen-Bradley 2711-TC1 is essential to ensure its optimal performance and longevity. Periodic inspection of the terminal should include checking for any signs of wear or damage on the touchscreen and ensuring the enclosure remains sealed.

Additionally, the LED backlight should be monitored for any signs of dimming or failure, and replacements should be made as necessary to ensure continuous operation. It's also crucial to verify that the ventilation slots are free from dust and debris to prevent overheating.

Regularly updating the terminal's firmware and software can enhance performance and address any potential vulnerabilities. Ensuring that all communication ports are secure and functioning correctly is also vital for maintaining robust connectivity within the industrial network.

Before performing any maintenance, always disconnect the Allen-Bradley 2711-TC1 from its power source to eliminate the risk of electric shock. Operators should be trained to handle the terminal safely, including proper techniques for touching the screen to avoid applying excessive force, which could damage the display.

Always use appropriate personal protective equipment (PPE) when handling the terminal, particularly in industrial settings where there might be additional hazards.

Frequently Asked Questions:

What is the operating temperature range of the Allen-Bradley 2711-TC1?

The operating temperature range of 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) further underscores its suitability for various operational conditions.

How much user memory does the Allen-Bradley 2711-TC1 have, and what does this mean for application storage?

The Allen-Bradley 2711-TC1 houses 64K of standard user memory, providing sufficient space for application storage and execution. This capacity allows for the efficient handling of various control programs and user applications.

How efficient is the power consumption of the Allen-Bradley 2711-TC1?

The Allen-Bradley 2711-TC1 features a maximum heat dissipation of 246 BTU per hour, highlighting its efficient power consumption management.

Product Specifications Table

Attribute Specifications
Series PanelView 1200
Voltage 90-264 VAC
LED Lifespan 100,000 hours
Communication Interface Remote I/O (RIO) and RS232
Weight 13.6 kg
Operating Temperature Range 0 to 50°C
Heat Dissipation 246 BTU per hour
Display size 12 inch
Touchscreen interface 640 x 480 pixels
Product Status Discontinued
