Description
-
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚ here.
OPERATOR INTERFACE - TOUCH SCREEN
- PANELVIEW PLUS 6
- 1000 COLOR TERMINAL 10.4 INCH
- STANDARD COMMUNICATION: ETHERNET AND RS-232
- 512 MB FLASH
- 512 MB RAM
- 100-240 VAC INPUT
- 50/60 HZ
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
The Allen-Bradley 2711P-T10C4A8 is an HMI component. It is a PanelView Plus 6 operator terminal that comes from the PanelView Plus product line, which is packed with a wide range of modern features and was introduced by this operator. It continues to be a reliable and affordable human-machine interface (HMI) technology that creates a real-time connection between processes and machines.
A 10.4-inch colorful active TFT matrix display is included. It has an adequate viewing size of 211 x 158 mm, 18-bit color visuals, and a resolution of 640 × 480. (8.3 x 6.2 in.). Additionally, it has a replaceable, detachable backlight with a minimum operating lifecycle of 50,000 hrs at room temperature. In addition to housing the input interface through an 8-wire analog-resistant touchscreen built for One million presses at an actuating force of 10 to 110 grams, the digital display houses process readout as well.
The inbuilt 9-Pin Sub-D digital interface, which belongs to the RJ45 Ethernet communication connection, is used by this module to transmit and receive data and information to/from partner automation gadgets. There are also USB host and device ports on this operator, which can connect external input devices such as a keyboard and mouse and removable storage through a USB flash stick.
The Windows CE 6.0 OS is included. This operating system offers several Windows OS capabilities, including VNC Access, PDF File Reader, ActiveX Controls, and File Transfer Protocol (FTP), while making the installation environment interface simpler. It has 512 MB of RAM & 512 MB of flash memory and is powered by a 100-240 VAC, 50-60 Hz external power source voltage.
Talking about measurements, it is 16 by 14 by 8 inches and weighs about 8 pounds. It may use up to 160 VA of power at once. It features RS-232 serial connections, Ethernet for communication, and additional DH-485, DH+, & ControlNet module connectors. It enables a connection via a 2711-NC13 communication line, FactoryTalk View Machine Version program, and an RS-232 and Ethernet communication connector. The user can operate the module using the touchscreen to enter data and information.
It also supports an SD card for data backup & logging. A real-time clock is included in the Allen-Bradley 2711P-T10C4A8 to record important data. The battery-operated clock has a 4-year minimum battery capacity. It performs significantly well regarding speed, transition speed, system memory, storage capabilities, and backlight brightness. The most popular firmware ranges from 6.01 to 8.10, and the most popular series is Category A and Category B.
