Allen-Bradley 1336F-B060-AN-EN

The Allen-Bradley 1336F-B060-AN-EN is an advanced adjustable frequency drive designed for industrial applications requiring consistent control over the speed and torque of alternating current (AC) motors. This specific model is an integral component in the renowned 1336F series, recognized for its strong performance and versatile configuration possibilities. As such, it plays a critical role in enhancing motor protection and operational efficiency.

Technical Specs:

The 1336F-B060-AN-EN produces 85.0 amps with three phases and 380“480 VAC input voltage. It can regulate motors up to 60.0 horsepower or 45.0 kilowatts, ensuring energy efficiency and effectiveness. The drive has an IP00 rating, making it suitable for installations with additional protective measures to prevent contact with active or rotating components.

Regarding performance enhancements, the drive integrates a number of functionalities specifically designed to conserve energy and safeguard the motor, especially when starting up. By aiding in the reduction of mechanical strains linked to motor initiations, it consequently extends the apparatuss operational longevity.

Moreover, the drive provides extensive configuration options to accommodate various operational requirements. Adjusting the frequency at the drives output from 0 to 400 Hertz enables precise motor speed regulation.

The drive incorporates a memory module and a rapid processor, both of which contribute to its streamlined and effective functioning. Combined with incorporated digital input/output capabilities, these components empower the drive to manage intricate and rigorous applications effortlessly.

Notwithstanding its sophisticated attributes, the drive comes without an enclosure. While this attribute affords installation flexibility, it necessitates proper housing in an appropriate environment to preserve its functionality and integrity. The drive exhibits a remarkable efficiency rating of 97.5%, underscoring its capacity to optimize energy utilization and reduce wastage.

Operating Conditions:

The Allen-Bradley 1336F-B060-AN-EN has been engineered to function optimally in particular environmental circumstances. The device operates at its highest efficiency below 50 degrees Celsius, rendering it appropriate for integration into controlled environments like air-conditioned control rooms or cabinets.

Additionally, this drive exhibits no deceleration at altitudes below 1000 meters, catering to most industrial facilities requirements at moderate elevations.

In addition, its operations non-condensing relative humidity level spans from 5% to 95%. This extensive range ensures the drives capability to withstand diverse levels of atmospheric moisture without compromising its functionality.

Nevertheless, to prevent potential harm and guarantee durability, it is advisable to install the drive in an area devoid of surplus dust and corrosive fumes, as such elements can impair electronic components and impede operation.

Applications:

The 1336F-B060-AN-EN is particularly well-suited for controlling large and powerful equipment, including pumps, conveyors, lifting devices, and fans. Due to its versatile configuration options and robust output capabilities, this device is well-suited for industries that heavily depend on mechanical movements and necessitate accurate control over such operations.

By providing dependable and effective motor control, this drive contributes to improving industrial processes safety and overall productivity, rendering it an invaluable asset across multiple sectors such as material handling, logistics, and manufacturing.

Frequently Asked Questions:

What is the power capacity of the Allen-Bradley 1336F-B060-AN-EN?

The Allen-Bradley 1336F-B060-AN-EN can manage a power output of 45.0 kilowatts or 60.0 horsepower. This capacity makes it appropriate for driving medium to large-sized industrial motors.

How does the IP00 rating affect the installation of the Allen-Bradley 1336F-B060-AN-EN?

The Allen-Bradley 1336F-B060-AN-EN is IP00-rated. Therefore, it cannot withstand precipitation or solid objects. Installation in a protected environment reduces damage and ensures operation safety.

What is the efficiency rating of the Allen-Bradley 1336F-B060-AN-EN, and why is it important?

The Allen-Bradley 1336F-B060-AN-ENs 97.5% efficiency rating shows its ability to transform electrical energy into mechanical energy, reducing energy waste and operational costs.
